Lexicon I-O | FW810S 10 Input/12 Output FireWire Audio Interface (Discontinued)

Part #:
IOFW810S
Model #:
I-O | FW810S
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL
The Lexicon® I-O|FW810S is more Lexicon I-O U22 Pro Tools 9 Compatiblethan just an 8-in, 10-out FireWire™ audio interface. It’s a pro recording studio contained in a single rack unit.

Description

The high-voltage, ultra low noise dbx mic pre’s on every channel provide optimal timbre and tonality on every track. And the newly updated Pantheon II plug-in provides smooth, lush Lexicon reverbs for creating ideal sonic spaces.

With built-in dbx Type IV™ conversion, your digital recordings will preserve their dynamic range even when levels get too high. They’ll acquire that forgiving, oversaturated quality once only found on big analog recorders. Type IV conversion actually gives you more headroom, capturing subtle details in higher level signals instead of hard clipping them.

Plus, the Lexicon I-O|FW810S adds a powerful software Mixer with integrated dbx dynamics (compresser, gate, limiter, EQ) to your digital audio workstation. The Mixer’s true-to-life interface design feels familiar from the second you start it, making it easy to adjust levels, route signals through 8 inputs and 10 outputs, and apply and preview reverbs and dynamics. And the I-O|FW810S does the processing, so you can mix and fine tune your recordings in real time with zero latency. You can even save and load snapshots of mixer settings. Save and load up to five monitor mixes – one for the main control mix, and up to four for individual band members. Or assign the I-O|FW810S to start up with a snapshot.

With so many powerful and useful recording studio tools, it’s more than just a FireWire interface. It’s the Lexicon I-O|FW810S.

Features

  • Zero latency Lexicon monitor reverb.
  • dbx® high-voltage, ultra low noise mic pre's on all 8 channels.
  • dbx dynamics (compressor, limiter, gate, EQ) on all 8 channels.
  • 6 analog combi-jack inputs on the rear panel for mic/line inputs.
  • 2 front panel combi-jacks accept mic, line, or instrument signals.
  • Type IV conversion feature emulates tape saturation at high levels.
  • Zero latency mixer hardware UI with dbx dynamics and a hardware monitor reverb.
  • 44.1 to 96KHz sample rates, 24 bit processing.
  • 8 analog TRS outputs (7.1 surround capable) and stereo main (control room) outs.
  • Stereo S/PDIF digital I/O.
  • MIDI In and Out.
  • FireWire 400 connection to DAW.
  • Software suite includes Steinberg's Cubase LE 4, Toontrack EZ Drummer lite, and Lexicon Pantheon II Reverb Plug-in.
  • Low Latency drivers include Windows WDM with ASIO support along with and Macintosh CoreAudio with ASIO support.

Specifications

Microphone Inputs Female XLR Pin 2 Hot
Input Impedance 3kW balanced
Phantom Power +48 Volts
Maximum gain +55 dB
E.I.N. (at max gain) −127 dB @ 55dB gain typical (150W source)−130 dB @ 55dB gain typical A-weighted (150W
Maximum Input Level +8 dBu
Frequency Response +/−1.5 dB, 20Hz - 20kHz
THD+N
Line Inputs 1/4" TRS balanced or unbalanced
Input Impedance 20kW balanced, 13kW unbalanced
Maximum Input Level +22 dBu
Frequency Response +/−1.5 dB, 20Hz - 20kHz
THD+N
Instrument Input 1/4" TS unbalanced
Input Impedance 500kW
Maximum Input Level +10 dBu
Frequency Response +/−2.5 dB, 20Hz - 20kHz
THD+N
Line Outputs 1/4" TRS balanced or unbalanced
Level +20 dBu maximum
Impedance 32W Balanced, 16W Unbalanced
Headphone Output 1/4" stereo jack 250mW per channel at 50W
MIDI Interface 5 pin DIN connectors for MIDI in and MIDI out
Sample Rate 44.1, 48, 88.2, or 96 kHz (determined by computerapplication)
Dynamic Range A/D (24 Bit) 110 dB typical, A-weighted, 20Hz -20kHz
Dynamic Range D/A (24 Bit) 110 dB typical, A-weighted, 20Hz -20kHz
Dynamic Range A/D/A (24 Bit) 108 dB typical, A-weighted, 20Hz -20kHz
Power Requirements 100 – 240 VAC, 50/60 Hz, 30 Watts
Dimensions 19”W x 1.7”H x 10.5”D
Weight 7.7 lbs
