Listen Tech LPT-M1 ListenPoint Microphone Media Interface Kit (Discontinued)

By Listen Technologies

Listen Tech LPT-M1 ListenPoint Microphone Media Interface Kit (Discontinued)

Name: Listen Tech LPT-M1 ListenPoint Microphone Media Interface Kit (Discontinued)
Brand: Listen Technologies
SKU: LT-LPT-M1
Price: 240 USD
Availability: OutOfStock

Write a Review

Part #:

LPT-M1

Model #:

LPT-M1

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The M1 Microphone Kit provides exceptional audio quality, ease of use and years of dependable service. The intuitive design allows the user to control microphone volume/mute and auxiliary input volume.

Description

The Listen Tech LPT-M1 ListenPoint Microphone Media Interface Kit is a wireless microphone used by teachers and students so they can clearly be heard by everyone in the classroom. It has the ability to interface to external sources wirelessly such smart phones and lap top computers. It offers exceptional audio quality, ease of use and years of dependable service. The intuitive design allows the user to control volume. The M1 uses advanced lithium ion battery technology and intelligent battery management to maximize battery life, minimize battery charging time and increases the time between battery replacements. The included drop-in charger makes charging simple and fast.

Features

Wireless microphone worn by the teacher (lanyard or belt worn)
Can also be used as a pass around microphone for students
Teacher can adjust volume of microphone and all other connected audio sources
Included drop-in charger
Connect your smart phone, lap top or other device directly
Advanced Lithium ion battery technology provides up to 8 hours of battery life and is charged in under 2 hours
Battery is replaced much less often than other battery types
Soft button can be customized to meet your specific needs, such as emergency call, screen control and more

Specifications

Audio
Internal Microphone	-50 dBu nominal, 100 Ohms, 100 Hz to 15 kHz, +/- 3 dB,< 2.0% (THD), >60 dB SNR
External Microphone	-50 dBu nominal, 100 Ohms, 100 Hz to 10 kHz, +/- 3 dB,< 2.0% (THD), >60 dB SNR
Auxiliary Input	-10 dBu nominal, 10k Ohms, 20 Hz to 20 kHz, +/- 3 dB,< 0.1% THD, >80 dB SNR
Infrared Emitter	38 kHz uplink
Infrared Sensor	2.3 MHz, 2.8 MHz, 3.3 MHz, 3.8 MHz
Controls & Indicators
Up Button	Volume up
Mute Button	Mute microphone and/or GPI control
Down Button	Volume down
Soft Button	GPI Control - programmed via software
Green LED	Solid - on/off, blinking - muted (twice per second)
Red LED	Solid - microphone fully charged, blinking - charging, rapid blinking - battery low capacity
Amber LED	Blinking - programming mode/multi-function operation
Beeper	Link to sensor is lost or low battery
Power
Battery Type	Lithium Ion
Battery Capacity	1180 mAh
Battery Charge time	< one (1) hour charge time
Operating time	8 hours minimum
Power Supply Input	100-240 VAC, 50-60 Hz, 0.4 A
Power Suppy Output	5 VDC
Power Supply Cord and Connector	0.09" (2.3 mm) OD, DC Plug
Power Supply Plugs	Removable plugs (types B, G, I and C included)
Microphone Dimensions (H x W x D)	4.3" (109 mm) x 2.0" (52 mm) x 0.75" (18 mm)
Microphone Weight (with Battery)	0.23 lb (0.10 kg)
Shipping Weight	1 lb (0.45 kg)

In The Box

(1) LPT-M1 ListenPoint Microphone/Media Interface
(1) LPT-A202 Handheld Sleeve
(1) LPT-A204 Clips (lanyard, handheld, and belt)
(1) LPT-A207 Lanyard
(1) LPT-A201 Charging/Storage Station
(2) Mounting Hardware - #8 Long Screws
(2) Mounting Hardware - #8 Wall Anchors
(1) LPT-A205 5 VDC Universal Power Supply (Includes -01,-02,-03 and -04 adaptors)
(1) LA-365 Li-ion Battery
(1) Quick Reference Card
(1) Attention Insert
