The LT-800-216-01-D is a 216 MHz stationary RF transmitter designed for assistive listening systems. Offering outstanding audio clarity, digital signal strength, and 57 selectable channels, it broadcasts strong, reliable audio to both belt pack and stationary receivers. The transmitter is suitable for a wide range of applications and connects to a main audio system to provide assistive listening.
Features balanced and unbalanced audio inputs for use with nearly any audio source, including mixers, microphones, and MP3 players. It is Dante adapter enabled through the LA-465 Dante adapter and includes a built-in auto processor that optimizes voice or music prior to transmission.
| Frequency Range | 216.01 - 216.99 MHz |
|---|---|
| Number of Channels | 19 wideband, 38 narrowband |
| Transmission Range | Up to 3,000 ft. (914 m) |
| Output Power | 100 mW |
| Frequency Response | 50 Hz - 15 kHz (±3 dB) |
| Signal-to-Noise Ratio | SQ enabled 70 dB, SQ disabled 50 dB |
| Audio Inputs | Balanced XLR or 1/4 in combo and unbalanced phono inputs |
| Audio Processing | Adjustable compression, 1:1 to 4:1 slope, 2:1 default |
| Dante Compatibility | Dante adapter enabled |
| Antenna Connector | BNC, 50 Ohms |
| Number of Simultaneous Transmitters | Up to 5 |
| Power Supply | 100-240 VAC, 50-60 Hz, 0.4A |
| Compliance | UL, CE, GS, TÜV, RoHS |
| Color | Dark Gray with white silk screening |
| Dimensions (H x W x D) | 1.75" (44.45 mm) x 8.50" (215.9 mm) x 9.13" (231.90 mm) |
| Weight | 3.5 lbs (1.6 kg) |
| Shipping Weight | 6 lbs (2.7 kg) |
