State of the art surge protector with auto-reset over/under voltage protection and remote power control is ideal for a wide range of applications. Model ACSPR-RPC1-1509(K) is ETL Listed in the US and Canada to UL Standard 60065. It is a 15A device that provides safeguarded power distribution from a slim rackmount chassis with three unswitched outlets and six switched outlets that can be remotely controlled. The 19"W x 1-3/4"H (1U) surge suppression device with remote power control and over/under voltage protection features multi-color LEDs for easy visual identification of system status. Termination is by a nine foot cord with NEMA 5-15P plug. Unit is offered with rocker or key switch activation.
| General | |
|---|---|
| Power Rating | 120VAC, 60Hz, 15A 1800W |
| Actuation Switch | Front panel rocker or keyswitch with momentary contacts (normally open SPST) plus rear barrier strip termination blocks for momentary (normally open) remote switches and DSP timed events |
| External Trigger Voltage | External Trigger Voltage |
| Alarm Interface | Lock on, lock off and switch lock functions for alarm system or master control panel applications |
| Over/Under Voltage Protection | All receptacles turn off when power in exceeds 140V or drops below 100V. Receptacles turn back on when power returns to acceptable range |
| External Control Connections | Plug-in barrier strip terminal blocks |
| Termination | 9 foot cord with NEMA 5-15P plug |
| EMI/RFI Filter | 19dB@500kHz, 42dB@30MHz |
| Safety Agency Approvals | ETL Listed in US and Canada to UL Standard 60065 “Audio, Video & Similar Electronic Apparatus’ |
| Surge Suppressor | |
| Maximum Surge Current | 72,000A (exceeds UL1449-3 6000V, 3000A) |
| Initial Clamping Voltage | 205V, UL rating 330V |
| Endurance | IEEE C62.41-1991, B3 (C1), Pulses (lifetime): 1kv≥1,000,000; 3kv≥100,000; 6kv≥5000 |
| Transient Noise Reduction | 25dB@100kHz, 50dB@1MHz |
| Response Time | Less than 5 nanoseconds |
| Protection Mode | Line to neutral, zero ground leakage |
| UL1449-2 Adjunct Results | 1000 surges, 6000 volts, 3000A, C1 and B3 waveforms (IEEE C62.41), No failures |
| Diagnostic LEDs | Left (Green): On = Ground verified Center (Green): On = Protection active Right (Red): On = Protection reduced |
| Applicable Standards | IEEE standard 587-80 A & B, IEEE standard C62.41-1991, IEC 1000-4-5-1995 (IEC 801-5) |
| Dimensions (H x W x D) | 1.75" (44.5 mm) x 19" (483 mm) x 9" (228.6 mm) |
| Weight | 12 lbs (5.44 kg) |
