The CV520 is a compact broadcast-quality POV camera designed for professional live production, streaming, sports, worship, education, and corporate AV applications. Built around a high-performance 1/1.8" progressive CMOS sensor, the CV520 captures sharp, color-accurate Full HD video with outstanding low-light sensitivity and enhanced dynamic range. Its interchangeable CS/C lens mount allows users to select the ideal lens for long-distance shots, specialty viewpoints, or customized production environments.
Designed for modern IP workflows, the CV520 supports simultaneous 3G-SDI, HDMI, and Ethernet video outputs, enabling seamless integration into traditional broadcast systems and network-based production environments. Advanced streaming support includes SRT, RTSP, RTMP, H.264, and H.265/HEVC codecs, providing reliable, low-latency video delivery while minimizing bandwidth requirements. Audio embedding capabilities and versatile remote control options make the camera an ideal solution for remote productions and distributed AV systems.
Housed in a rugged aluminum alloy chassis with rear I/O protection, the CV520 is built for dependable operation in demanding environments. Remote configuration and image adjustments are available through VISCA over IP, RS485, and a browser-based web interface, while flexible power options, including PoE and 12 VDC, simplify installation. Combining premium image quality, advanced streaming technology, and professional connectivity, the CV520 delivers a versatile camera solution for today's broadcast and AV professionals.
Note: CS/C Mount Lens Sold Separately
| Image Sensor | 1/2.86" Progressive CMOS, 2.12MP |
|---|---|
| Resolution | Full HD 1920 x 1080 |
| Video Output | 3G-SDI & IP Streaming |
| Streaming Protocols | SRT, RTMP, RTSP |
| Video Compression | H.264/H.265 (HEVC) |
| Lens | Included M12 4 mm Lens |
| Minimum Illumination | 0.01 Lux (Day), 0.005 Lux (Night) |
| Frame Rates | Up to 1080p60 |
| Audio Input | Line-Level Audio Embedding |
| Remote Control | VISCA over IP, VISCA over RS485, Web GUI |
| Image Processing | WDR, BLC, 2D/3D Noise Reduction, Anti-Flicker |
| White Balance | Auto, Manual, Indoor, Outdoor, ATW |
| Power Options | 12 VDC Power Input |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Dimensions (H x W x L) | 2.4" (61 mm) x 2.52" (64 mm) x 4.53" (115.18 mm) (without lens) |
| Weight | 0.90 lbs (0.41 kg) |
