Marshall V-LCD171MD 17.3" Full Resolution 1920 x 1080 Rackmount Monitor (Discontinued)

Name: Marshall V-LCD171MD 17.3" Full Resolution 1920 x 1080 Rackmount Monitor (Discontinued)
Brand: Marshall Electronics
SKU: MARSHALL-V-LCD171MD
Price: 1335.99 USD
Availability: OutOfStock

Write a Review

Part #:

V-LCD171MD

Model #:

V-LCD171MD

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Marshall V-LCD171MD monitor provides excellent features in a popular 17" size. Straight-forward design with the most-used features built-in including waveform and audio bar overlays, loudspeakers, programmable function buttons, three-color tally lights and tilting mount design for easy viewing. Great for use in news vans, satellite trucks and central equipment rooms. The V-LCD171MD base unit comes with no preinstalled module.

Description

Marshall V-LCD171MD 17.3" Full Resolution 1920 x 1080 Rackmount Monitor
with Modular Input, Waveform Overlay, Audio Bars, Loud Speakers and HDMI Loop-Out

Marshall V-LCD171MD monitor provides excellent features in a popular 17-inch size. Straight-forward design with the most-used features built-in including waveform and audio bar overlays, loudspeakers, programmable function buttons, three-color tally lights and tilting mount design for easy viewing. Great for use in news vans, satellite trucks and central equipment rooms. The V-LCD171MD base unit comes with no preinstalled module.

The V-LCD171MD-3G option includes the base unit with a preinstalled MD-3GE module providing an additional 3G/HD/SD-SDI input with loop-through.

Features

Full HD 1920 x 1080 display
HDMI input / output standard
Modular design. Allows addition of 3GSDI input
Waveform monitor at the push of a button
Audio meter bars overlay
Built-in speakers and headphone jack
Rugged 4-pin XLR power connector
Three color (Red, Yellow, Green) LED tally lights

Specifications

Dimensions (H x W x D)	10.46" (265.68 mm) x 17.30" (439.42 mm) x 1.33" (33.78 mm)
Weight	7.65 lbs (3.47 kg)
