- Description
Details
The miniature wideband Mipro ACT-71Ta bodypack transmitter is built on the experience and backbone of three generations of wireless products. The ACT-71Ta features a smaller package with improved RF circuitry, a lightweight magnesium alloy housing, premium low power consumption characteristics, backlit LCD display, silent on/off switch and 72 MHz of bandwidth. The Mipro ACT-71Ta is innovative and reliable, offering the premium performance needed by today's audio professionals.
- Features
Features
- Ultra-Wide bandwidth - 72 MHz
- Durable lightweight miniature magnesium alloy body
- High SPL input with proprietary "Photo-cell Coupling" dynamic range modulation circuitry
- Backlit LCD displays working channel and battery status
- Selectable impedance for different inputs
- Sensitivity gain adjustment
- Silent on/off switch with mute button and optional MJ-70 remote mute switch control
- End user lockout function
- Programmable RF power and audio gain levels
- Mini-XLR connectivity with threaded bayonet attachment
- Detachable belt clip
- Mipro's world first ACT function, allowing rapid and precise transmitter frequency set-up
- Specification
Oscillation Mode PLL Synthesized Carrier Frequency Range UHF 482 - 698MHz (TV 16 - 51) Bands 5UA, 5US & 6UA Bandwidth 72MHz Channel Set-Up Mipro ACT (Automatic Channel Targeting) IR Sync RF Output Power 50mW or 10mW (switchable) Spurious Emissions <-55dBc Peak Deviation ±68KHz Max Input Level 0dBV Sensitivity Gain Adjustment -18dB, -12dB, -6dB, 0dB, +6dB, +12dB Optional Headworn and
Lavaliere Microphones & CablesMU53LX, MU53HNS, MU55LX, MU55HNX, Avlex HS/HSP Series, MU40GX Inst. Cable Battery AA Alkaline x 2 Dimensions (H x W x D) 2.8" (70 mm) x 2.5" (63 mm) x 1" (26 mm) Weight (Excluding Batteries) 0.17 lbs (0.077 kg) - Reviews
