MIPRO AD-708 UHF Wideband 4-Channel Auto Gain-Control Antenna Divider
Compatible with MIPRO's Series 7 wideband systems or any other true diversity receivers that operate within its frequency range of 470 to 850 MHz, the MIPRO AD-708 features four UHF diversity receivers that can be operated from just a pair of antennas, greatly reducing installation clutter and increasing receiving range, signal integrity and efficiency.
It integrates an innovative Auto Gain-Control System that automatically detects, controls and precisely compensates for signal loss of antenna cables when used with the MPB-30 gain-controllable antenna booster. It solves complex antenna system installation issues, optimizes signal reception and system performance without worrying about calculating signal-loss of antennas, cables, and the specifications of boosters.
It also features a buffered aux in and out for linking additional dividers in multi-channel systems without compromising signal integrity. It also utilizes wide dynamic range and low noise components, advanced circuit design featuring very low intermodulation distortion and greatly reduces spurious interference in multiple channel applications.
| Frequency Range | UHF 470 - 850 MHz |
|---|---|
| IIP3 | +32 dBm |
| RF Output Gain | +1.0 dB ± 1 dB |
| Input/Output Gain | +1.0 dB ± 1 dB |
| Output Port Isolation | >18 dB at 400 - 1000 MHz |
| Filter Selection | Low sideband ≧35 dB High sideband ≧30 dB |
| Input / Output Connectors | 2 sets of 1-to-4 active divider outputs 2 sets of 1-to-1 active outputs, TNC Female, 50 Ω Impedance |
| Antenna Input Power Supply | Antenna A/B input port supplies bias 8.3 V DC, 230 mA max. to booster |
| Signal Loss Detection | Detects the signal loss of cables automatically |
| Power Supply | 12 - 15 V DC |
| Current Consumption | Approx. 242 mA at 12 V DC Input |
| Dimensions (H x W x D) | 1.7" (44 mm) x 16.5" (420 mm) x 7.1" (180 mm) |
| Weight | 3.3 lbs (1.5 kg) |
