MXL V67I Dual Diaphragm Studio Condenser Microphone

The V67I dual diaphragm large capsule cardioid condenser microphone offers versatile studio-quality performance for a wide range of recording applications. Featuring two selectable capsules, one warm and one bright, the V67I allows precise tonal control to suit different instruments and vocal styles. A convenient switch lets you toggle between capsules during sessions for maximum flexibility.

Designed for high-fidelity recording, the V67I delivers a flat, natural frequency response, making it perfect for stringed instruments, cymbals, percussion, and other acoustic sources. Its large diaphragm condenser design captures subtle nuances with clarity and detail, while the cardioid polar pattern minimizes unwanted ambient noise.

To maintain optimal performance, high-quality microphone cables such as Mogami Gold Studio Microphone Cables are recommended. The dual-diaphragm design and selectable capsules make the MXL V67I a versatile and reliable choice for professional studio engineers, home studios, and live instrument tracking.

Features

Features

Dual-diaphragm large capsule condenser microphone with bright and warm selectable capsules
Interchangeable cardioid and omnidirectional capsules for maximum recording flexibility
Flat frequency response for natural and pure audio capture
Ideal for stringed instruments, cymbals, percussion, and acoustic sources
Dual-diaphragm design captures subtle sonic details and dynamics
Easy capsule selection switch for quick tone adjustments during recording
Compatible with high-quality studio cables for optimal sound performance
Studio and live-use microphone suitable for professional engineers and home studios

Specification

Diaphragm	32 mm/6 and 8 Micron Gold-Sputtered
Frequency Response	20 Hz - 20 kHz
Polar Pattern	Cardioid
Sensitivity	22 mV/Pa
Impedance	200 ohms
Attenuation Switch	0 dB, -6 dB
High Pass Filter	6 dB/octave @ 150 Hz
Equivalent Noise	20 dB (A-Weighted IEC 268-4)
S/N Ratio	78 dB (Ref. 1 Pa A-Weighted)
Max SPL for .5% THD	140 dB
Power Requirements	48V Phantom Power
Metal Finish	Green with Gold Grill
Dimensions (Dia x L)	1.85" (47 mm) x 7.24" (184 mm)
Weight	1.3 lbs (0.59 kg)
