NEXO P12-PW 12-Inch 2-Way White Point Source Speaker

The P12-PW is a high-output, multi-purpose point source loudspeaker designed for demanding professional audio applications. Featuring a custom coaxial 12" neodymium LF driver with a 3" diaphragm HF driver, the P12-PW delivers exceptional clarity, phase coherence, and up to 138 dB peak SPL. Its white compact, curvilinear enclosure makes it ideal for both front-of-house and wedge monitor use, with or without a companion subwoofer.

Built from custom 15 mm bent birch and poplar plywood, the P12-PW combines lightweight construction with outstanding acoustic performance and durability. The speaker supports switchable passive or active operation (touring versions), allowing flexible system design when paired with NEXO NXAMP powered controllers. Dual ultra-low distortion bass ports ensure clean, controlled low-frequency output even at high sound pressure levels.

The P12-PW's modular directivity system allows coverage to be adapted in seconds. Supplied with a standard 60° x 60° horn, the speaker can be fitted with optional 90° x 40° or asymmetrical magnetic flanges to precisely match venue requirements. With a comprehensive range of mounting accessories and compatibility across touring and fixed installation environments, the NEXO P12-PW is a versatile solution for professionals who demand power, precision, and flexibility.

Features

Features

12" 2-way full-range coaxial point source loudspeaker
High-output design delivering up to 138 dB peak SPL
Coaxial neodymium LF driver with 3" diaphragm HF driver
60° x 60° coverage with optional interchangeable dispersion flanges
Switchable passive or active operation (touring versions)
Lightweight 15 mm bent birch and poplar plywood enclosure
Ultra-low distortion dual-shaped bass ports
Suitable for FOH, stage monitoring, and multi-purpose applications
Compatible with NEXO NXAMP powered TDcontrollers
White structural paint finish for professional environments

Specification

Frequency Response @-6 dB	60 Hz to 20 kHz
Peak SPL@1m	138 dB Peak (Passive mode)/140 dB Peak (Active mode)
Operating Voltage	55 Vrms (150V peak)
HF Dispersion	60° x 60° (Default) - 90° x 40° (with 90 x 40 flange) - 60°~100° x 40° (with PS flange)
Crossover Frequency	60 Hz, 85 Hz
Nominal Impedance	Active mode: (8Ω LF + 8Ω HF)/Passive mode: 8Ω
Components	1 x Coaxial Neodymium LF 12" 8 Ohms long excursion & HF 3" 8 Ohms
Number of Ways	2 ways passive (2+/2- P12) or 2 ways active (1+/1- LF, 2+/2- HF) switchable
Connectors	4 x NL4, 4 poles connectors (1 per handle + 2 at the back)
Rigging Points	1 x universal accessory fit on each side + 1 x on the bottom
Material	Custom made bent plywood of baltic birch and poplar
Color	White
Front Finish	Steel front grille + back mesh
Operating Temperature Range	0°C - 40°C (32° F - 104°F)
Storage Temperature Range	-20 °C - 60°C (-4°F - 140°F)
Dimensions (H x W x D)	20.9" (531 mm) x 17" (432 mm) x 12.4" (317 mm)
Weight	44 lbs (20 kg)
