The One Systems CFA2.HTH CrossField Array-2 is a two-way long-throw speaker that provides very high intelligibility, wide frequency response and prodigious acoustic output.

Description

The CrossField Array-2 (CFA2.HTH) is a two-way long-throw speaker that provides very high intelligibility, wide frequency response and prodigious acoustic output. Unlike many other "long-throw" speakers, the CFA2.HTH's configuration of 6 x large-format drivers are direct-radiators instead of being horn loaded. This design provides far better intelligibility and wider, smoother response that reproduces both voices and music with a high level of accuracy. The CFA2.HTH's combination of high sensitivity and prodigious power handling provides high acoustic output capability. To add to its installation flexibility, the CFA2.HTH's HF array is rotatable and its LF array is a 2 x 2 configuration permitting the enclosure to be oriented horizontally or vertically. The enclosure is made of hand-laminated, gel-coated fiberglass with fully reinforced M10 suspension inserts. The CFA2.HTH's enclosure is very compact for a system that provides such high output, intelligible, full-range audio. To add to its installation flexibility, a range of optional U-Brackets, pan/tilt, and pole mount brackets are available. For long-throw applications, the CFA2.HTH's is an excellent solution.

Features

  • Very High Intelligibility
  • 316-Grade Stainless Steel Rigging
  • Long Throw/High Acoustic Output
  • Fully Rotatable High Frequency Waveguide
  • IP 56 Direct Weather Rated
  • Double Large Format High Frequency Drivers
  • 4 x 10" (254mm) Low Frequency Long Throw Array (2x2 array configuration)
  • Multiple Fly Points and Rigging Accessories

Specifications

Frequency Response 60Hz - 16kHz
Coverage Pattern 55º x 30º Fully Rotatable
Passive Crossover Frequency 1500 Hz
System Sensitivity (1 Watt / 1 Meter) 104dB
Power Handling 1200W continuous
2400W program
4800W peak
Input Impedance (Lo Z) 4-ohms
Weather Performance IEC 529 IP 56
Mil Spec 810
Dimensions (H x W x D) 34.5" (876.5 mm) x 22.5" (572.6 mm) x 17.6" (446.3 mm)
Weight 133.6 lbs (60.6 kg)
