OWI AMP-IC6 Self-Amplified Ceiling Speaker (Discontinued)

Part # AMP-IC6
Model # AMP-IC6

The OWI AMP-IC6 Self-Amplified Ceiling Speaker can deliver up to 25 watts of class AB power directly to the speaker. Each powered speaker can drive three additional speakers and one line can drive up to 20 self-amplified speakers.


Description

Details

Discontinued Product. Authorized OWI Dealer. Perfect Condition.

The OWI AMP-IC6 UL Listed Self-Amplified, 6.5" Ceiling Speaker can deliver up to 25 watts of class AB power directly to the speaker. Each powered speaker can drive three additional speakers. One line can drive up to 20 self-amplified speakers. 12 Volt AC power supply included.

Equipped with many of the new and most popular installer features, the AMP-IC5 power module is made to expressly fit into the OWI Models IC6 coaxial speaker providing a high fidelity module.

By being within inches of the speaker, the amplifier facilitates maximum damping control of the speaker due to low source impedance resulting in maximum high fidelity reproduction.

Tailor-designed and dedicated specifically to match the speaker, the amplifier effectively delivers optimum response. The power module has critical design features that facilitate fast and easy installation in the field.

Features

Features

  • Amplifier built onto the OWI IC6 In-Ceiling Speakers
  • Can effectively drive up to three additional non-amplified IC6 In-Ceiling Speakers
  • Up to 25W of class AB power right at the speaker
  • Lower noise feature
  • Fast and easy install in the field
  • 12V AC power supply (UL rated) included
  • Protected from shorts and overheating
  • Line level volume control available
  • Speaker combination program available
  • UL listed
Specification
Impedance8Ω
Sensitivity (1W/ 1M)86dB
Dispersion120°
Max Power (8Ω)50W
Nominal Power (8Ω)25W
Frequency Response65 Hz ~ 20 kHz
Woofer Size6.5"
Woofer MaterialPaper, PP Coated
Tweeter Size0.5"
Tweeter MaterialPEI
Grill MaterialAluminum
PaintableYes
Cut Out Size (Dia)Φ 7.63" (193.8 mm)
Overall Dimensions (Dia x D)9" (228.6 mm) x 2.5" (63.5 mm)
Weight2.5 lbs (1.13 kg)
Documents

Documents

In the Box

In the Box

  • (1) OWI AMPIC6 Self-Amplified Ceiling Speaker
