| Mic Input Gain Adjustment Range | 10 dB to 60 dB |
|---|---|
| Mic Input to Left/Right Balance Output | 87 dB (max gain) |
| Line Input Gain Adjustment Range | -10 dB to 40 dB |
| Line Input to Left/Right Balance Output | 67 dB (max gain) |
| Stereo Line Input Gain Adjustment Range | Off to +20 dB |
| Stereo Line Input to Left/Right Output | 44 dB (max gain) |
| Aux Return to Left/Right Balance Output | 21 dB (max gain) |
| Residual Noise (Master Left/Right) | -98 dBu,-90 dBu,-84 dBu |
| Residual Noise (Monitor Send) | -103 dBu,-84 dBu |
| Residual Noise (Effects Sends) | -103 dBu,-84 dBu |
| S/N Ratio (Ref: +4 dBu) (Master Left/Right) | 102 dB,94 dB,90 dB |
| S/N Ratio (Ref: +4 dBu) (Monitor Send) | 107 dB,88 dB |
| S/N Ratio (Ref: +4 dBu) (Effects Sends) | 107 dB,88 dB |
| Frequency Response(Mic Input to Left/Right Output) | 14 Hz to 25 kHz +0 dB/-1 dB |
| (10 Hz to 80 kHz BW) | |
| Equivalent Input Noise (EIN) | -129 dBu (input terminated with 150 Ohms) |
| Crosstalk | >80 dB Adjacent Input Channels (1 kHz);>75 dB Left to Right Outputs (1 kHz) |
| Common Mode Rejection Ratio (Mic Input) | 50 dB minimum (20 Hz to 20 kHz);70 dB typical @ 1 kHz |
| Meters | 6 segment, peak reading (0 dB = +4 dBu) |
| Signal/Overload Indicators | Red LED lights 3 dB below clipping |
| Power Requirements | Domestic: 16 VAC 60 Hz; 12 Watts nominal |
| Dimensions - Unpacked | 9.375" W x 3" H x 11.75" D |
| Dimensions - Packed | 17.25" W x 4.5" H x 12" D |
| Weight - Unpacked | 7.10 lbs (3.22 kg) |
| Weight - Packed | 9.00 lbs (4.082 kg) |
