Presonus StudioLive 24 Series III Digital Mixer

Home /
Presonus StudioLive 24 Series III Digital Mixer (Discontinued)

Description

Details

Presonus StudioLive 24 Series III 32 Input Digital Live and Recording Mixer with Motorized Faders

The PreSonus StudioLive® 24 digital console/recorder is by far the most powerful mixer in its class. This third-generation StudioLive mixer is fully recallable, with 25 touch-sensitive motorized faders and 25 recallable XMAX preamps. Yet despite its extensive features, the StudioLive 24 actually improves upon PreSonus®' legendary ease of use while letting you customize its workflow and operations. The StudioLive sound is better than ever, including all-new Fat Channel processing, re-engineered from the ground up, and vintage-style EQs and compressors. Add built-in AVB networking, onboard multitrack Capture™ recording to SD Card, and a complete suite of software, and you have a mixing and recording powerhouse that's equally formidable in live and studio applications.

PreSonus Capture™ recording software is an intuitive, rock-solid multitrack recording application with virtual soundcheck. It's installed directly into the StudioLive 24 so you can leave your laptop at home. Capture's one-touch recording makes it easy to record to the StudioLive 24's onboard SD multitrack recorder. When you're finished recording, open your Capture session in Studio One® for Mac® and Windows® (included), and the entire mix scene will transfer to your Studio One session, including fader levels, Fat Channel settings, and, yes, any drum solos that you may have had to endure that night.

The StudioLive 24's Fat Channel has received a major overhaul while continuing to offer digital precision with the heart and soul of analog. Our new Fat Channel implements a plug-in-style workflow that features vintage-style EQ and compression options on every channel, from classic tube limiters to passive EQs. And in addition to channel processing, the StudioLive 24 offers 6-band, fully parametric EQ on all mix outputs. Enjoy extensive, studio-style processing when recording on location or running shows on the road!

StudioLive 24 goes above and beyond in providing ways to customize things to best fit the way you work. Now you can customize your Fat Channel layout, putting the parameters you care about most right at your fingertips. There are even several workflow options to personalize your mixing experience. For instance, you can control the mixer with a multiple iPads and—optionally—a computer, each running UC Surface with a different view, enabling you to see and touch all of the controls you need at a given time.

With StudioLive 24, we've upped the ante and given you more flexibility when working with scenes and presets. Mixer scenes now include Scene Safe. Similarly, we've expanded the concept of Fat Channel presets so that presets have, for practical purposes, become like scenes for individual channels, not only saving input and Fat Channel settings but also aux send and bus assignments. Of course you can also use preset filters to choose what you want to recall.

Don't you hate it when you're setting up for a show and find you have an unused subgroup—but you're short one monitor mix? That's not a problem anymore, thanks to 16 FlexMixes that can be individually designated as aux, subgroup, or matrix mixes. You get a total of 10 FlexMixes on analog outputs, 6 on XLR connectors, and 4 on ¼-inch TRS; the other 6 are routed over USB or AVB. These 16 FlexMixes are in addition to the 4 fixed subgroups that also are available via USB or AVB, giving you a total of 20 mix buses, not counting the main mix, solo, and FX buses. We also provided 24 DCAs so you can more easily and flexibly control groups of channels. These are only a few of the many ways you can customize your StudioLive 24 mixer exactly to your needs and workflow.

The back panel of a StudioLive 24 console sports all of the connections you need for live sound and studio production. With flexible connectivity, superior audio quality, the ability to customize for your workflow, and powerful processing, mixing, and routing capabilities, you'll create your mixes in whatever manner works best for you. We just provide the tools.

Features

Features

General Controls:

25 touch-sensitive, motorized faders with 1-to-1 workflow
RGB Select buttons with user-assignable colors
Transport control
All-new Fat Channel controls including
8 scribble strips, encoders, and multicolor buttons
Customizable user layer
7-inch color touchscreen
DAW control (Studio One, MCU, and HUI) coming soon

Inputs and Outputs:

32 total inputs
24 channel inputs: 16 mic, 8 mic/line
1 XLR Talkback mic input with recallable XMAX Class A preamp
2 stereo Aux inputs
10 FlexMix outputs: 6 XLR, 4 balanced TRS
Unbalanced stereo (RCA) tape input and output
Bluetooth™ 4.1 wireless tape input
Stereo AES/EBU digital output
2 XLR (L/R) Main outputs
XLR Main summed mono output
2 TRS monitor outputs
Stereo headphone output

Channels and Buses:

32 input channels

24 with recallable XMAX Class A mic preamps
8 via USB and AVB

2 stereo aux inputs
26 buses:

16 FlexMixes (can be designated as aux, subgroup, or matrix mixes)
4 dedicated subgroups
4 internal effects sends
Stereo main bus

24 Filter DCAs for easily and flexibly controlling groups of channels

Networking Connections:

1 Ethernet control network port

Dynamic, Self Assigned, and Manual IP address modes

1 Ethercon AVB audio network port
Complete ecosystem of AVB solutions, including stageboxes and personal monitor mixers available

Recording:

Onboard 34x34 SD recorder (using Capture™)
38x38 USB recording interface
55x55 AVB recording interface

Specification

Microphone Preamplifier
Input Type	XLR Female, balanced
Frequency Response to Main Output	20-20 kHz, ±0.5 dBu (at unity gain)
Input Impedance	1 kΩ
THD to Main Output	<0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
S/N Ratio to Main Output	(Ref = +4 dB, 20 kHz BW, unity gain, A-wtd) 94 dB
Common Mode Rejection Ratio	(1 kHz at unity gain) 65 dB
Gain Control Range	(±1 dB) 0 dB to +60 dB
Maximum Input Level	(unity gain) +12 dBu
Phantom Power	(±2 VDC) 48 VDC, switchable per channel
Line Inputs
Type	¼” TRS Female, balanced
Frequency Response to Main Output	20-20 kHz, ±0.5 dBu (at unity gain)
Input Impedance	10 kΩ
THD to Main Output	<0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
S/N Ratio to Main Output	(Ref = +4 dB, 20 kHz BW, unity gain, A-wtd) 94 dB
Maximum Input Level	+18 dBu
Tape Inputs
Type	RCA Female, unbalanced (stereo pair)
Maximum Input Level	+12 dBu, ±0.5 dBu
XLR Outputs
Type	XLR Male, balanced
Maximum Output Level	+24 dBu, ±0.5 dBu
Output Impedance	100Ω
Line Outputs
Type	¼” TRS Female, balanced
Maximum Output Level	+18 dBu, ±0.5 dBu
Output Impedance	100Ω
Tape Outputs
Type	RCA Female, unbalanced (stereo pair)
Maximum Output Level	+18 dBu, ±0.5 dBu
Output Impedance	100Ω
Headphone Output
Type	¼” TRS Female, active stereo
Maximum Output	100 mW/ch. @ 60Ω load
Frequency Response	20 Hz – 20 kHz (± 0.5 dB)
THD+N	0.01%, 1 kHz, max gain, 20 Hz BW, unwtd
S/N Ratio	96 dB, 1 kHz, max gain, 20 Hz BW, unwtd
System Crosstalk
Input to Output	-90 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)
Adjacent Channels	-87 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)

ADC Dynamic Range	115 dB (A-wtd, 48 kHz)
DAC Dynamic Range	115 dB (A-wtd, 48 kHz)
USB Recording Port	USB 2.0, Type-B
Bluetooth™ Input	4.1, stereo
AES/EBU Output	XLR Male
Network Control Port	RJ-45
AVB Audio Network Port	Ethercon
Internal Processing	32-bit, floating point
Sampling Rate	48 kHz
A/D/A Bit Depth	24
Reference Level for 0 dBFS	+18 dBu
Total System Latency	1.9 ms (local routing, analog in-analog out, all processing active)
Clock
Jitter	<20 ps RMS (20 Hz - 20 kHz)
Jitter Attenuation	>60 dB (1 ns in, 1 ps out)
Power/Environmental
Connector	IEC
Input-Voltage Range	90 to 230 VAC (±10%)
Power Requirements	85W (continuous)
Recommended Ambient Operating Temperature	0° to 40° Celsius / 32° to 104° Fahrenheit
Physical
Dimensions (H x W x D)	7" (179 mm) x 25.6" (650 mm) x 23" (584 mm)
Weight	30 lbs (13.6 kg)
