Presonus StudioLive 32.4.2 AI Digital Mixing System with Active Integration (Discontinued)

Name: Presonus StudioLive 32.4.2 AI Digital Mixing System with Active Integration (Discontinued)
Brand: PreSonus
SKU: PRESONUS-StudioLive 32.4.2AI
Price: 2299.95 USD
Availability: OutOfStock

Write a Review

Part #:

StudioLive 32.4.2AI

Model #:

StudioLive 32.4.2AI

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Digital Mixing the next generation With its incredible signal-processing power on every channel, easy store and recall of every setting and the ability to record it all with just two mouse clicks, a StudioLive mixer will spoil you fast.

Description

The 32-channel, 14-aux PreSonus StudioLive 32.4.2AI starts with all the strengths of previous StudioLive models—and then pushes the technology to the next level.
StudioLive 32.4.2AI is built with next-generation Active Integration technology that adds unprecedented power for mixing consoles anywhere near this price class. So while the 32.4.2AI looks and feels much like its non-AI counterparts it has with far more computing power, which makes possible some very useful new features.

For starters, you get twice as many internal effects buses and 31-band graphic EQs. We’ve added six mute groups and user-assignable Quick Scene buttons. You’ll love the ability to create two complete sets of EQ and dynamics settings for a channel or bus and then make quick A/B comparisons at the touch of a button.

A built-in 48x34 FireWire S800 interface is standard equipment but Thunderbolt and Ethernet (Dante) cards are expected by the end of 2013. A dedicated USB 2 port and included Wi-Fi LAN adapter lets you control the mixer wirelessly even without a Mac or Windows PC.

The deeper you dig into the StudioLive 32.4.2AI’s capabilities, the more you will realize that the future of digital mixing starts here and now.

A quick look at the StudioLive 32.4.2AI reveals a now-familiar, user-friendly mixing surface. It sports 100 mm faders for the 32 channels, 4 subgroups, and main bus. As with all StudioLive mixers, convenient knobs and buttons abound, and all core mixing features are immediately accessible from the mixing surface, without using the LCD, providing an intuitive, analog-like user experience.

Features

32 mic/line inputs with high-headroom Class A XMAX mic preamplifiers.
4 subgroups.
Stereo/mono main out.
14 auxiliary mixes.
48-in/34-out FireWire S800 digital recording interface (24-bit/44.1 kHz and 48 kHz).
Studio One Artist Digital Audio Workstation software for Mac and Windows.
Capture 2.0 recording software for Mac and Windows.
StudioLive Remote-AI mixer-control software for iPad available free from Apple App Store.
QMix-AI aux-control software for iPhone and iPod touch available free from Apple App Store.
Direct recording interface compatible with Logic, Nuendo, Cubase, Sonar, Digital Performer, Ableton Live, and more.
60 channel strips.
Trim control with –20 to +20 dBV line/-15 to +65 dBu mic gain range (80dB!).
+48V phantom power switch for condenser microphones.
Digital Audio Input Select.
100 mm precision faders.
Lighted Solo and Mute buttons.
6 mute groups with All On/All Off switches.
Access to Fat Channel functions.
15-LED ladder metering + clip LED.
Analog ¼" insert (rear panel).
4 subgroup buses.
14 aux sends.
4 internal effects sends (two reverbs, two delay effects).
Master Section.
Fat Channel with rotary encoders.
Limiter: variable Threshold -28 dBfs to 0, ∞:1 Ratio.
Alt EQ & Dyn button for quick A/B comparisons of two complete sets of Fat Channel settings for each channel and busOutput Assign: 4 subgroups and main.
All settings can be copied among channels and buses and can be saved as user presets.
50 channel-strip presets for drums, bass, guitars, keyboards, and vocals.
4 internal digital effects-processors (2 reverbs, 2 delays), each with 50 customizable presets.
16 31-band graphic equalizers.
Scene Store and Recall.
Individual channel-strip setting storage.
Lockout mode to keep inspired amateurs from changing your settings.
Metering/Displays.
8 x 15-LED main meter bank.
15-LED horizontal Pan/Balance display.
64 x 194 LCD matrix.
Input/Output:
32 main inputs, each with XLR mic, ¼" line, and ¼" inserts.
2 ¼" balanced stereo (L/R) aux inputs.
1 XLR talkback-mic input with XMAX preamp, phantom power (always on), and level control.
Unbalanced RCA stereo (L/R) tape inputs and outputs.
XLR stereo (L/R) main outputs with level control.
¼" balanced stereo (L/R) main outputs.
XLR mono output with level control.
¼" balanced stereo (L/R) control-room outputs.
¼" headphone output.
4 ¼" balanced subgroup outputs.
14 ¼" balanced aux outputs.
32 pre-insert, balanced direct outputs, Ch. 1-8, 9-16, 17-24, 25-32 (DB25 sockets).
Dedicated USB 2.0 port and included Wi-Fi LAN adapter for wireless communications.
Installed Option Card with:
S/PDIF digital out.
2 FireWire S800 ports.
Optional I/O cards.
Thunderbolt-FireWire S800-S/PDIF Out.
Ethernet/Dante-FireWire S800-S/PDIF Out.
Digitalia.
High-definition analog-to-digital converters (118 dB dynamic range).
Unlimited-headroom, 32-bit floating point, digital mixing and effects processing.
Internal sample frequency 44.1 kHz and 48 kHz.
Physical:
Rugged, non-flex steel chassis.
100 mm long-throw faders.
Military-grade, quick-touch buttons.
BNC 12V lamp socket.
Optional dust covers available.

Specifications

Microphone Preamp 1-32 (XLR Balanced)	Specifications
Type	XLR Female, Balanced
Frequency Response to Direct Output	20 Hz to 40 kHz ±0.5 dBu
Frequency Response to Main Output	20 Hz to 20 kHz ±0.5 dBu
Input Impedance (Balanced)	1 kΩ
THD to Direct Output	< 0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
THD to Main Output
EIN to Direct Output	+125 dB unwtd, +130 dB A-wtd
S/N Ratio to Direct Output	-97 dB
S/N Ratio to Main Output	-94 dB
Common Mode Rejection Ratio	+65 dB
Gain Control Range	-16 dB to +67 dB (± 1 dB)
Maximum Input Level (unity gain)	+16 dBu
Phantom Power	+48 VDC
Line Inputs	Specifications
Type	¼" TRS Female, balanced mono
Frequency Response to Direct Outputs	10-40 kHz, 0 / -0.5 dBu
Frequency Response to Main Outputs	20-20 kHz, ±0.5 dBu
Input Impedance	10 kΩ
THD to Direct Output
THD to Main Output
S/N Ratio to Direct Output	-105 dB
S/N Ratio to Main Output	-94 dB
Gain Control Range (±1 dB)	-20 dB to +20 dB
Maximum Input level (unity gain)	+22 dBu
Tape Inputs	Specifications
Type	RCA Female, unbalanced (stereo pair)
Maximum Input Level	+22 dBu
Auxiliary Inputs	Specifications
Type	¼" TRS Female, balanced (2 stereo pairs)
Maximum Input Level	+22 dBu
Main Outputs	Specifications
Type	Male, balanced (stereo pair); ¼" TRS Female, balanced (stereo pair); XLR Male, balanced (mono)
Rated Output Level	+24 dBu
Output Impedance	100Ω
Subgroup Outputs	Specifications
Type	¼" TRS Female, balanced (mono)
Rated Output Level	+18 dBu
Output Impedance	100Ω
Tape Outputs	Specifications
Type	RCA Female, unbalanced (stereo pair)
Rated Output Level	+18 dBu
Output Impedance	100Ω
Control Room Outputs	Specifications
Type	¼" TRS Female, balanced (stereo pair)
Rated Output Level	+18 dBu
Output Impedance	100Ω
System Crosstalk	Specifications
Input to Output (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)	-90 dBu
Adjacent Channels (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)	-87 dBu
Noise Gate / Expander	Specifications
Threshold Range	-84 dB to 0 dB
Attack Time	0.02s to 500 ms / 0.5 ms
Release Time	0.05s to 2s
Expander Attenuation Range	2:1
Gate Attenuation Range	-84 dB to 0 dB / ∞
Key Listen Filter	2nd-order resonant bypass; Q=0.7; OFF, 40 Hz-16 kHz
Limiter	Specifications
Threshold	-28 dBFS
Ratio	∞:1
Attack	20 ms
Hold	10 ms
Release	20 ms
Compressor	Specifications
Threshold Range	-56 dB to 0 dB
Ratio	1:1 to 14:1
Attack Time	0.2 ms to 150 ms
Release Time	40 ms to 1000 ms
Auto Attack and Release	Attack = 10 ms, Release = 150 ms
Curve Types	hard and soft knee
EQ	Specifications
Type	2nd-order shelving filter (Q = 0.55)
Low (Lowpass or Bandpass)	36 to 465 Hz, ±15 dB
Low Mid	36 to 465 Hz, ±15 dB
Low Mid	90 Hz to 1.2 kHz, ±15 dB
High Mid	380 Hz to 5 kHz, ±15 dB
High (Highpass or Bandpass)	1.4 kHz to 18 kHz, ±15 dB
Q	0.1 to 4 / Low Q= 0.55, Hi Q=2.0
Graphic EQ	Specifications
31-Band 1/3rd Octave Controls	Curve-fitting algorithm
Gain/Attenuation	±15 dB
Digital Audio	Specifications
ADC Dynamic Range (A-wtd, 48 kHz)	118 dB
DAC Dynamic Range (A-wtd, 48 kHz)	118 dB
FireWire	S800, 800 Mb/s
Internal Processing	32-bit, floating point
Sampling Rate	44.1, 48 kHz
A/D/A Bit Depth	24
Reference Level for 0 dBFS	-18 dBu
Clock	Specifications
Jitter
Jitter Attenuation	>60 dB (1 ns in ≈ 1 ps out)
Power/Environmental	Specifications
Connector	IEC
Input-Voltage Range	90 to 240V, 50-60 Hz
Power Requirements	200W
Temperature Range	0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit
Physical	Specifications
Length	21.31 inches (541.27 mm)
Width (chassis only)	31.5 inches (705.60 mm)
Maximum Height	7.02 inches (178.21 mm)
Weight	50 lbs. (22.68 kg)
