This 120-watt microphone amplifier takes your voice to the next level! The amplifier's wide frequency response makes it suitable for amplifying music or vocal program material. It can be used for live bands, office paging systems, public announcements, or a variety of other installations. It's got two front ¼' inputs for mics, each with its own independent volume control and talkover. Plus, there's two stereo RCA inputs on the back - including one that takes low level phono input from a turntable. The 3-band EQ (100 Hz, 1 kHz, 8 kHz) lets you tweak the sound to your exact requirements. This amp is compatible with 70 V PA systems too. An unswitched outlet on the back means you'll never be looking for an outlet. Runs on 110 and 220V.
| Output Power at THD 10%, 1 kHz | 40W |
|---|---|
| Max. Power | 120W |
| THD at 1W, 1 kHz Low-Pass Filter | MIC 1: 1% MIC 2: 1% AUX/CD: 1% PHONO: 1% |
| Frequency Response (at 1W, +/- 3 dB) | MIC 1 & MIC 2: 80 Hz - 20 kHz AUX/CD: 80 Hz - 20 kHz PHONO (RIAA 100 Hz/10 kHz) +13 dB/-13.5 dB |
| Input Sensitivity (at 10% THD, 1kHz) | MIC 1 & MIC 2: 2.5 mV AUX/CD: 150mV PHONO: 3.5mV |
| Signal-Noise Ratio (Input Shorted) with WTD | MIC 1 & MIC 2: 60dB AUX/CD: 70dB PHONO: 60dB |
| Noise Level (Input Shorted) | 0.75mV |
| Equalizer Control Range | 100 Hz: +/- 10 dB1 kHz: +/- 10 dB8 kHz: +/- 10 dB |
| Power Requirement | 120V AC, 60 Hz/240V AC, 50 Hz |
| Power Fuse | 120V AC: 1.5A240V AC: 0.75A |
| Dimensions (H x W x D) | 3.33" (85 mm) x 12.75" (324 mm) x 8.9" (226 mm) |
| Weight | 8.64 lbs (3.92 kg) |
