QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair
QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair
QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair
QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair
QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair

By QSC Audio

QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling Loudspeaker 70/100V with 16-Ohm Bypass - Pair

Write a Review
Part #:
AD-C6T-HC
Model #:
AD-C6T-HC
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112
Email

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM 1-888-256-4112
Email Contact us by email or
our simple form. SEND EMAIL
The QSC AD-C6T-HC is a 6.5", 2-way ceiling-mount loudspeaker with 75° coverage, ideal for high ceilings and reverberant spaces. It features high power handling, magnetic grille, and Q-SYS™ voicings for optimal sound in any installation.

Description

QSC AD-C6T-HC AcousticDesign 6.5" 2-Way High Ceiling In-Ceiling Speakers

The AD-C6T-HC is a 6.5-inch, 2-way ceiling-mount loudspeaker designed for venues with high ceilings or acoustically challenging, reverberant spaces. It delivers a tight 75° coverage pattern and higher power handling for focused, intelligible sound. The loudspeaker maintains consistent tonal characteristics with the rest of the AcousticDesign Series, allowing seamless integration across different form factors. It features a snap-fit magnetic grille for clean aesthetics, and a 3x double-stepped, long-travel dog-ear blind mount system for secure, easy installation. Advanced Intrinsic Correction™ voicings are available via Q-SYS™ for optimized performance, and it includes a 16 Ω bypass along with multiple transformer taps for 70/100 Vrms distributed audio systems. The AD-C6T-HC is available in white (RAL 9010).

Features
  • Higher power handling and tighter coverage area enables venues with high ceilings or reverberant spaces
  • Consistent tonal characteristics across the entire AcousticDesign Series let you mix and match form factors across your venue
  • Snap-fit magnetic grille
  • 3x double stepped, long travel dog-ear blind mount system
  • Advanced Intrinsic Correction™ voicings available via Q-SYS™
  • 16 Ω bypass with multiple transformer taps for 70/100 Vrms systems
  • 75° coverage pattern
  • Available in white (RAL 9010)

Specifications
LF Driver 6.5" (165 mm) paper cone woofer, 1.75" (44.5 mm) voice coil
HF Driver Ferrite magnet 1.4" (35.6 mm) kapton dome compression tweeter
Frequency Range (-10 dB) 45 Hz - 20 kHz
Coverage 75° conical
Rated Noise Power / Voltage 120 Wrms
Sensitivity (dB) 90 dB @ 1 W, 1 m
Max SPL (@ 1m) 110 dB Continuous / 116 dB Peak
Rated Bypass Impedance 16 Ω
Transformer Taps / Impedance 7.5 W, 15 W, 30 W, 60 W / 15 W, 30 W, 60 W
Input Connector Type 4-pin Euroblock connector with parallel output
Enclosure Material Powder coated steel back can
Grille Material Powder coated steel
Cut-Out Dimensions (Dia) 12" (305 mm)
Dimensions (Dia x H) 13.4" (340 mm) x 12" (313 mm)
Shipping Dimensions (H x W x D) 14.2" (360 mm) x 32.5" (825 mm) x 17.5" (445 mm)
Net Weight (Individual) 19 lbs (8.58 kg)
Shipping Weight (Pair) 48.9 lbs (22.16 kg)
