QSC AD-DWL.360 5.25" 2-Way Direct Weather Landscape Loudspeaker with 360° Coverage

QSC AD-DWL.360 5.25" 2-Way Direct Weather Landscape Loudspeaker with 360° Coverage

Name: QSC AD-DWL.360 5.25" 2-Way Direct Weather Landscape Loudspeaker with 360° Coverage
Brand: QSC Audio
SKU: QSC-AD-DWL.360
Price: 780 USD
Availability: InStock

Write a Review

Part #:

AD-DWL.360

Model #:

AD-DWL.360

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

All AcousticDesign™ Series Direct Weather models address the variabilities of outdoor environments with an elevated bollard design, allowing sound to travel above obstructions for an optimal listener experience. The 360° coverage angle enables full coverage to comply with individual environmental requirements.

Description

QSC AD-DWL.360 Direct Weather Landscape Loudspeaker with 180° Coverage

Optimal Outdoor Sound Experience

Impact Resistance

Featuring direct-to-concrete or in-earth base supports for permanent installation as well as tamper-resistant screws and a rugged exterior, the AcousticDesign™ Series Direct Weather family mitigates damage from accident or attempted tampering.

All Weather Durability

With an Ingress Protection (IP) Rating of IP55, durable polypropylene/fiberglass construction and stainless-steel hardware, this series is built to withstand the long-term outdoor exposure.

Advanced QSC Loudspeaker Voicings

To further enhance performance and speed of install with optimum result, advanced voicing filter sets using QSC Intrinsic Correction™ techniques are available via Q-SYS or CXD Series amplifier platforms for a complete QSC systems solution.

Features

5.25 in (135 mm) in weather-resistant cone woofer; (2x) 1 in (25 mm) aluminum dome tweeter
360° focused outdoor coverage
Reliable 60W 70 / 100V transformers with 16 Ω bypass
Maximum peak SPL 110 dB (16 Ω bypass)
Includes direct-to-concrete mounting collar (burial mounting option via AD-DWL.BASE accessory)
Tamper resistant stainless-steel hardware
Rugged F1-F2 UL Rated polypropylene/fiberglass construction exterior
Unobtrusive green color and style allows it to blend with the environment (or paintable exterior allows for further customization)
Advanced voicing filter sets using QSC Intrinsic Correction™, available through either Q-SYS or CXD Series amplifier platform
Meets Ingress Protection (IP) rating of IP-55 for dust and splash resistance

Specifications

Effective Frequency Range	55 Hz - 25 kHz
Rated Noise Power	80W
Coverage Angle (-6 dB)	360° (500 Hz – 5 kHz)
Maximum Continuous SPL	104 dB
Maximum Peak SPL	110 dB
Rated Impedance	16 Ω
Transformer Taps	7.5W, 15W, 30W, 60W / 15W, 30W, 60W
Transducer	(1) 5.25" (135 mm) weather resistant cone woofer, ferrite magnet, rubber surround (1) 1" (25 mm) aluminum dome tweeter, rubber surround
Input Connector Type	Wire pig-tail, blunt
Enclosure Material	Glass-Filled polypropylene, F1-F2 UL Rated
Grille Material	Polyester fabric on polycarbonate frame
Mount	Direct to concrete
Ingress Protection	IP - 55
Testing	Exceeded MilSpec819 standard for humidity, salt spray, temperature, and UV Passed Mil-STD-202f standard for salt spray (specific to electrical components)
Included Accessories	Direct-to-concrete mounting collar
Dimensions (H x W x D)	30.16" (766 mm) x 6.46" (164 mm) x 6.46" (164 mm)
Net Weight	10.36 lbs (4.7 kg)
