The QSC PL340 Power Amplifier is designed for the most demanding live audio users, whether in touring rigs or fixed installations. The most requested features of the PowerLight 2 series have been upgraded to deliver "the ultimate analog amplifier", while the QSC Dataport ensures full compatibility with advanced digital processing and QSControl. Three models range in power from 1250 watts to 4000 watts per channel at two ohms, all in two-rack space chassis that are only 15.6" (40 cm) deep and 22 lbs (10 kg).
In addition to higher power, the PowerLight 3 Series offers higher input voltage, selectable sensitivity, and easily adjusted rear panel switches with color coded LED indicators. For those users who simply want a high performance amplifier to go with their existing processor or console, the PowerLight 3 Series is an ideal choice, offering high power, excellent value, and zero signal latency. When complete integration of amplifier control, monitoring and DSP is desired, the PowerLight 3 Series is fully compatible with the QSControl BASIS networked audio platform, with its comprehensive drag and drop DSP functionality. Simpler DSP requirements can be met with the DSP-4 processing module.
| 8 ohms EIA 1 kHz 1% THD | 800 W |
|---|---|
| 4 ohms EIA 1 kHz 1% THD | 1250 W |
| 2 ohms EIA 1 kHz 1% THD | 2000 W |
| 8 ohms EIA 1 kHz 1% THD | 2600 W |
| 4 ohms EIA 1 kHz 1% THD | 4000 W |
| 8 ohms | 0.002-0.01% |
| 4 ohms | 0.005-0.01% |
| 2 ohms | 0.02% |
| Maximum Distortion | 20 Hz - 20 kHz, 1 dB below rated power |
| 4 to 8 ohms | 0.05% |
| Frequency Response (8 ohms) | 20 Hz - 20 kHz, +/-0.2 dB |
| Noise (20 Hz - 20 kHz, 32 dB Gain) | -105 dB |
| Dynamic Headroom (4 ohms) | 2 dB |
| Damping Factor (8 ohms) | 500 |
| Output Circuitry | Class H (2-tier) |
| 26 dB Setting | 3.92V |
| 32 dB Setting | 1.96V |
| Input Gain (1.2V setting) | 36.4 dB |
| 1.2V Setting | 11V (+23 dBu) |
| 32 dBu Setting | 14.6V (+25.5 dBu) |
| 26 dBu Setting | 25V (+30 dBu) |
| 120V 50/60 Hz | 12A |
| 230V 50 Hz | 7A |
| 120V 50/60 Hz | NEMA-15 |
| 230V 50 Hz | CEE 7/7 16A |
| Chassis Power Connector (All Voltages) | 20A PowerCon |
| Input Impedance | > 10k ohms balanced, or unbalanced |
| Cooling | Variable-speed fan, rear-to-front air flow |
| Connectors (each channel) | Input: XLR Male, XLR Female and 3-pin detachable terminal blocks (1 each per channel) |
| Front Indicators (LED color) | Power (Blue); Bridged (Yellow); Parallel (Orange); Clip/Prot |
| Rear Controls (with LED indicators) | Input Mode: Bridge (Yellow); Stereo (Green); Parallel (Orange); |
| Amplifier and Load Protection | Short circuit, open circuit, thermal, RF protection. On/off muting, |
| Dimensions | 3.5" H x 19.0" W x 15.63" D (89 mm x 483 mm x 397 mm) |
| Weight | 22.0 lbs (10.0 kg) |
| Shipping Weight | 31.5 lbs (14.3 kg) |
