QSC E215 E Series Dual 15-inch 2-Way Passive Loudspeaker
The QSC E215 is a trapezoidal, two-way loudspeaker featuring dual 15-inch 500W (continuous) die-cast aluminum frame woofers with a 3.5-inch voice coil. It employs a Frequency-shading topology across both woofers to maximize low-frequency output while minimizing interference through the HF crossover transition. It is intended for use when high-power and extended low-end are needed from a single full-range loudspeaker. A large format 2.8” compression driver attached to the 75° DMT™ waveguide assures that even distant listeners will be well covered.
The E Series is a range of passive loudspeakers offering robust construction, trusted reliability and overall sonic performance beyond expectations. Intended for sound reinforcement in entertainment applications including live performance, DJ and dance music, karaoke and event production, E Series loudspeakers will deliver outstanding results. Building on QSC's proven “Systems” methodology, the E Series loudspeakers' performance is further enhanced when paired with QSC's GXD or PLD amplifiers or with a QSC TouchMix digital mixer and taking advantage of the onboard DSP and factory-tuned presets. These presets support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music, and karaoke.
- Features
Features
- High output, professional quality sound with 1000W continuous power
- E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers
- E Series Entertainment System DSP Tunings are now available for PLD, CXD and GXD processing amplifiers
- Titanium diaphragm for high fidelity and long life
- Rugged tour-grade textured paint
- Foam-lined perforated steel grill
- Optional Padded Cover for protection during transportation
- Optional M10 rigging kit available for permanent installation
- Specification
Configuration 2 x 15-inch, 2-way, non-powered Frequency Range (-10 dB) 39 Hz – 20 kHz Power Capacity Continuous: 1000W
Peak: 4000WSensitivity 98 dB, 1 W @ 1 m Coverage Angle 75° conical DMT Output (Peak SPL @ 1m) 134 dB Drivers LF: 2 x 381 mm (15") driver with 89 mm (3.5") voice coil
HF: 38 mm (1.5") exit, 71 mm (2.8") voice coil, compression driver
Nominal Impedance: 4 ΩCross-Over Full-range only, 1.8 kHz Input Connectors 2 x NL4
1 x barrier stripEnclosure 11-ply, black texture paint finish. Perforated, powder-coated steel grille with foam lining Dimensions (H x W x D) 44.3" (1125 mm) x 16.5" (420 mm) x 18.3" (464 mm) Net Weight 108 lbs (49.1 kg) - Documents
