The Radial Engineering JX44 Air Control is a high-performance guitar signal manager designed for the most demanding professional concert stages where wireless guitar systems, acoustics, effects, and multiple amplifiers are used simultaneously. It features 4 inputs. Effects loops, six amplifier outputs and much more.
To ensure the highest quality signal transfer, the four instrument inputs employ Radial Engineering's unique class-A buffering topology with 100% discreet components. Inputs A & B are augmented with Drag™ Control load correction that lets you 'dial in' the perfect load for the most natural tone, while inputs B &C are equipped with a trim level that let you quickly balance signal levels.
There are two effects loops: A remotely controllable 'local' effects loop provide an easy interface to drawer-filled pedals or multi-effects processors and the built-in Radial Engineering SGI-44 (Special version of the Studio Guitar Interface) provides a noise-free connection to-and-from distant pedalboards to distances of 100 meters. A Radial Engineering direct box works double duty as an acoustic guitar output to the PA or as a direct feed for recording. With the JX44, you can record a 'clean guitar track' and use the built-in Radial Engineering X-Amp in post-production to re-amplify the signal to multiple amplifiers and pedals at the same time. With a JX44 in your rig, fixing a bum note for the live release is now possible.
Up to six guitar amplifiers may be used at once. Outputs 1 and 2 are single while outputs 3 and 4 are doubled-up to drive stereo amp setups or multiple stacks. All outputs are transformer isolated to eliminate hum and buzz from ground loops. These also feature 180º polarity reverse switches to ensure all amps are in absolute phase. Amps can be selected from the front panel or from the JR5 remote. This five function footswitch is equipped with internal memory that lets you store 4 amp scenes and recall them with single foot action.
⚠️WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
| Circuit Type | Radial Engineering proprietary Class-A signal path |
|---|---|
| Instrument Inputs | 4 x ¼” Hi-Z at rear panel |
| Input Impedance | Inputs A & B : variable w/ Drag™ from 10k - 1 megOhm; Inputs C & D : 1 meg Ohm |
| Amplifier Outputs | 6 x ¼” Hi-Z (unity gain) with 6 x Radial Engineering customwound transformers for amp isolation |
| Tuner Output | ¼” Hi-Z buffered instrument level (unity gain) |
| Local Effects Loop | Send ¼” Hi-Z output / Receive ¼” Hi-Z return (unity gain) |
| Power Supply | 15 VDC 1A center positive (two supplied) |
| Construction | 14-gauge steel with baked enamel finish |
| Dimensions | 19” 1RU x 66” deep |
| Weight | 7.6 lbs (3.44 Kg) |
