The ES 3160-II is a mixer-amplifier with 4 mic-line audio inputs on removable connectors (the first input also has an XLR socket), CD/USB/Bluetooth – MP3 player and tuner and an aux input for an additional external music source. The amplifier nominal power is 160 W, available on either a low impedance output (min. 4 Ω) or 100 – 70 V constant voltage output (for loudspeakers having 100 – 70 V transformers). Input 1 has a signal detection circuit (‘VOX’) providing automatic priority operation. All inputs 1, 2, 3 and 4 can access the priority through an external command (connected to the removable connector). Inputs 2 and 3 also have an RJ 45 socket for quick connection of an RCF BM 3001 paging microphone (through CAT5 cable).

A USB port (on the front panel) allows connection of a USB flash drive containing MP3 files. Aux outputs are available to send the internal / external music source signals to additional amplifiers, mixers, phone systems (‘music on hold’ function), etc. The 4 mic.-line inputs have a common ‘presence’ control and separate highpass filters that are useful for improving speech intelligibility.

• CD-USB/MP3 Player / FM tuner / Mixer Amplifier, Bluetooth connection with external device
• IR Remote control for CD - USB/MP3 player & tuner functions
• Full digital technology amplifier 160W RMS, 100V-70V and 4 Ohm outputs
• 4 universal inputs with phantom facility, Presence Control and per-channel High-Pass filters
• RJ45 connectors on input 2 and 3 for connection to BM3001 microphone
• Screw terminal connections, additional XLR and RJ45 input connections available
• Configurable Priority settings, VOX facility on input 1
• Selectable aux input for music source with volume and tone controls
• USB port on front panel allows reproduction of MP3 files from a memory stick
• Music On Hold and PRE outputs
