The S-4000M is a REAC merge unit that allows you to merge multiple REAC devices to enable a whole new world of configurations. The S-4000M merges up to four Digital Snake heads, such as the S-0808, S-1608 and S-4000 series, and merges the input/output to a single REAC signal. Ports 1 to 4 supply REAC embedded power to compatible products such as the S-0808. The intelligent Auto Map function assigns input channels automatically. REAC master devices recognize the S-4000M as a single REAC slave unit even when multiple digital snake heads are connected.
The S-4000M also serves as a distributor of outputs and/or splitter. Any inputs returning from Port A (Master) are distributed to the outputs depending on the devices connected. When S-0808s are connected, specific output assignments can be set. The M-400/M380 V-Mixer or dedicated PC Remote Control Software (S-4000RCS) configures routing, input gain, PAD and phantom power.
| Product Type | REAC Merge Unit |
|---|---|
| Connectors | REAC (RJ-45 EtherCon type) x 1 REAC EMBEDDED POWER (RJ-45 EtherCon type) x 4 REMOTE (RS-232C, DB-9 type) x 1 |
| Indicators | REAC EMBEDDED POWER: Red x 4 LINK: Green x 5 POWER: Blue x 1 AUTO MAP SLAVE UNITS: Red x 1 |
| Switches | POWER x 1, MODE x 1, AUTO MAP SLAVE UNITS x 1 |
| Power Supply | AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz) |
| Power Consumption | 1.6A/AC 115 V/AC 117V 0.9A/AC 220 V/AC 230 V/240 V (At max output of REAC EMBEDDED POWER) |
| Accessories (Included) | Power Cord, (5)REAC Connector Covers, (5)Ferrite Cores, (4)Rubber Feet, (4)Fastening Screws, Manual |
| Dimensions | 3.44" H x 8.63" W x 14.06" D (87 mm x 218 mm x 356 mm) |
| Weight | 6 lbs 10 oz (3.0 kg) |
