The Rolls MX122 is a five channel audio mixer which combines a single microphone signal with four stereo instrument or line level signals. The XLR Microphone input has a trim control and switchable +12 VDC phantom power available. The unit is ideal for musicians needing to mix stereo keyboards and sound modules with a single microphone.
| Input Impedance | |
|---|---|
| Line | 10 K Ohms unbalanced |
| Mic | 10 K Ohms balanced |
| Phantom Power Voltage | +12 VDC |
| Output Impedance | 50 Ohms bal |
| Max Input Level | +24 dBV line, -8 dBV microphone |
| Phase Shift | < 10 deg. 20 Hz - 20 kHz |
| Connectors | 8: 1/4" TS Inputs, 1: XLR Mic Input3: 1/4" TRS, 1: 1/8" (3.5mm) Outputs |
| Max Gain | 26 dB Line26 dB Aux80 dB Mic |
| Mic CMRR | 95 dB |
| S/N Ratio | >90 dB |
| THD | < .004% |
| IMD (SMPTE) | < .004% |
| Self Noise | < - 82 dB |
| Power | 12 VDC |
| Dimensions(H x W x D) | 8.4" (21.34 cm) x 1.7" (4.32 cm) x 5" (12.7 cm) |
| Weight | 2.5 lbs (1.14 kg) |
