The MX54s Pro-Mix Plus mixes three microphones into two transformer balanced outputs. It has three XLR inputs, each with individually switchable phantom power and Low Cut switches, a Level control and a Pan control. As mentioned, it has two transformer balanced, XLR outputs. A 1/4 inch Aux/Headphone output has been provided along with a Clip indicator, Power indicator and Power switch. The unit is also powered by two 9-Volt alkaline batteries.
| Input Impedance | 600 Ohms |
|---|---|
| Output Impedance | XLR 600 Ohms |
| THD + Noise | .02% |
| S/N Ratio | 84 dB |
| Frequency Response | 25 Hz - 16 kHz (+0 / -3 dB) |
| Max Output Level | + 14 dB |
| Max Input Level | -14 dB |
| Max Gain | +60 dB |
| Low Cut | -3 dB @ 100 Hz |
| Current Draw | 20 mA |
| Phantom Power | +18 VDC |
| Connectors | 3 Female XLR, 2 Male XLR, 1 1/4" TRS,DC Power Jack |
| Dimensions(H x W x D) | 5.3" (13.46 cm) x 3.7" (9.4 cm) x 2" (5.08 cm) |
| Weight | 1 lbs (0.45 kg) |
