Rolls PA71 MicroMix Power Amplifier (Discontinued)

Rolls PA71 MicroMix Power Amplifier (Discontinued)

Name: Rolls PA71 MicroMix Power Amplifier (Discontinued)
Brand: Rolls Audio
SKU: ROLLS-PA71
Price: 65 USD
Availability: OutOfStock

Write a Review

Part #:

PA71

Model #:

PA71

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Rolls PA71 mixes an XLR microphone signal with stereo (mixed to mono) RCA signals. The combined signal is sent to spring loaded output terminals via a seven watt power amplifier.

Description

The PA71 mixes an XLR microphone signal with stereo (mixed to mono) RCA signals. The combined signal is sent to spring loaded output terminals via a seven watt power amplifier. The unit also features a 1/4" Line/Powered output. The XLR input features switchable 12VDC phantom power. This unit is ideal for small room applications where a simple mix of a microphone with a cassette or cd player is needed.

Features

RCA Inputs
XLR Mic Input
Spring-loaded output
Low noise, efficient operation

Specifications

Line Input Impedance	47K Ohms
Mic Input Impedance	600 Ohms
Phantom Power Voltage	12V
Power Output	7 Watts (8 Ohms)
Voltage Gain	40 dB
Maximum Supply Voltage	18 VDC
THD	.05% typical
Total Input Noise	3 mV
Efficiency	65%
Input Sensitivity	28 mV
Bandwidth	20Hz - 25 kHz
Dimensions (H x W x D)	1.5" (38.1 mm) x 4.25" (108 mm) x 2.38" (60.3 mm)
Weight	1 lbs (0.45 kg)
