The XM Series multi-channel amplifier series features 4-channel high power models, The current switching allows for a compact and lightweight design (10kg). This series utilizes the newly developed 2U shell, Via the rear panel, models can be switched between stereo and parallel for each channel. This offers compatibility with a wide range of applications. Highly precise dB display detented attenuators, dedicated to each channel, are located on the front panel. The models also feature a protection circuit that allows you to monitor its status with an indicator. Attention to detail for better practicality can be found wherever you look, In addition to XLR input terminals, this series is equipped with Euro-block input terminals for easy connectivity. Outputs utilize a 5-way binding post and are also equipped with monitor/remote terminals and a subsonic filter. The models have been designed with all sorts of usage in mind.
| Power Output Level 20Hz - 20kHz1kHz THD+N=0.2%, 8Ω | 180W x 4 |
|---|---|
| Power Output Level 20Hz - 20kHz 1kHz THD+N=0.2%, 4Ω | 250W x 4 |
| Sensitivity, RL=8. Att.max | +4dB |
| S/N Ratio, 20Hz-20kHz (DIN AUDIO) | 100dB |
| Idle Power Consumption | 40W |
| 1/8 Power Consumption (4Ω) | 500W |
| Power Bandwidth, (Half power THD+N=0.5%) | 10Hz – 40kHz |
| Intermodulation Distortion, 60Hz: 7kHz, 4:1, half power | 0.1% |
| Frequency Response, f=20Hz-20kHz | -0.5dB, 0dB, 0dB |
| Residual Noise, 20Hz-20kHz (DIN AUDIO) | -70dB |
| Voltage Gain, 8Ω, f=1kHz | 100 |
| Sensitivity, ATT. max | 30dB |
| Maximum Input Voltage | 22dB |
| Input Impedance | 30kΩ (balance) 15kΩ (unbalance) |
| Controls, Front panel | POWER switch (push on/push off), attenuator (31position) x 4 |
| Controls, Rear panel | MODE switch (STEREO/BRIDGE/PARALLEL) x 2HPF switch (OFF/20Hz/55Hz 12dB/oct) x 2 |
| Connectors, Output | 5–way binding post/ch |
| Connectors, DATA PORT | D-sub15P, Monitor: Output Level/ch, Active/ch , Model Detect Control: Mute/ch |
| Connectors, Power | AC inlet x 1 |
| Indicators, POWER | x 1 (Green) |
| Indicators, SIGNAL | x 4(Green) |
| Indicators, CLIP/LIMIT | x 4 (Red) |
| Indicators, PROTECT/MUTE | x 4 (Red) |
| Load Protection | POWER switch on/off mute, DC-fault output relay off |
| Dimensions (H x W x D) | 3.44" (88 mm) x 18.88" (480 mm) x 16.25" (412.2 mm) |
| Weight | 22 lbs (10kg) |
