Sennheiser SK 6000 Digital Wireless Bodypack Transmitter A1 - A4 (Discontinued)

Sennheiser SK 6000 Digital Wireless Bodypack Transmitter A1 - A4 (Discontinued)

Name: Sennheiser SK 6000 Digital Wireless Bodypack Transmitter A1 - A4 (Discontinued)
Brand: Sennheiser
SKU: SENN-506318
Price: 1999 USD
Availability: OutOfStock

Write a Review

Part #:

506318

Model #:

SK 6000 BK A1-A4

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

The lightweight SK 6000 digital pocket transmitter can be combined with lavalier microphones and headsets, and shines as a high-end solution for instruments like guitar and bass. Maximum transmission reliability of the renowned Long Range mode and outstanding audio quality of the Sennheiser Audio Codec (SeDAC) are shared with the wireless masterpiece, Digital 9000. Sophisticated electronics prevent disturbing intermodulation, even with numerous transmitters in the most confined spaces. This allows operation in an equidistant frequency grid and efficiently utilizes the available frequency spectrum.

The right microphone for every application: Sennheiser lavalier microphones MKE 1, MKE 2 and MKE 40, Headsets HSP 2, HSP 4 and SL Headmic.

A special magnesium housing offers the perfect balance between light weight, inconspicuous size and rugged construction with shielding against moisture. The BA 61 lithium-ion battery pack ensures up to 6.5 hours of operation. Alternatively, operation is also possible with batteries from the B 60 battery set.

Additionally, the transmitter is compatible with the EK 6042 and EM 9046 in Long Range mode.

Features

Sennheiser 3-pin connector allows connection to a variety of microphones or an instrument
Highly effective intermodulation protection
AES 256 encryption and Digital 9000 encryption
Compatible with EK 6042 and EM 9046 in Long Range mode
Li-ion battery packs with 5.5 hours run time
Magnesium housing

Specifications

Modulation Scheme	Digital modulation Long Range Mode
Audio Codec	SeDAC (Sennheiser Digital Audio Codec)
Frequency Range	SK 6000 A1 - A4: 470 - 558 MHz
Switching Bandwidth	88 MHz
Frequency Stability	< 5 ppm
Tuneability	25 kHz steps
Encryption	AES 256 and Digital 9000 encryption
Lower Cut-Off-Frequency	Mic: adjustable, 30 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz Line: 30 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz
RF Output Power	25 mW rms, 50 mW peak
Audio Frequency Response	Mic: 30 Hz to 20 kHz (3 dB) Line: 30 Hz to 20 kHz (3 dB)
Audio Gain	Mic: adjustable in 3 dB steps from 0 dB to +42 dB Line: adjustable in 3 dB steps from −6 dB to +9 dB
Operating Time	6.5 h (with BA 61 battery pack)
Power Consumption	Max. 960 mW
Input Impedance	Mic: 22 kΩ Line: 1 MΩ
Mic/Line Input	3-pin audio socket
Instrument Cable Emulation	Adjustable cable length with 3 steps
Antenna Output	Coaxial socket
Dimensions (H x W x D)	2.99" (76 mm) x 2.44" (62 mm) x 0.79" (20 mm) (with BA 61 battery pack)
Weight	Approx. 0.32 lbs (0.147 kg) (with BA 61 battery pack and belt clip)
