Sennheiser SL Bodypack DW for SpeechLine System

Part #:
505900
Model #:
SL Bodypack DW-4-US
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The compact but robust Sennheiser SL Bodypack DW is optimized for speech in presentations or lectures where every word matters.

Description

The compact but robust Sennheiser SL Bodypack DW is optimized for speech in presentations or lectures where every word matters. It is compatible with all Sennheiser mircophones such as SL Headmic 1 or MKE 1. Thanks to bi-directional communication between transmitter and receiver, no settings need to be adjusted on the transmitter. The automatic frequency and interference management allows convenient and reliable operation. The LC display provides the link name, battery status and reception quality. The easy-to-access mute-slider makes the use of the microphone very convenient. The SL Bodypack DW comes with a rechargeable Li-Ion battery with external charging contacts - for easy charging with the CHG 2 - and a USB socket.

Features

  • Automatic frequency and interference management
  • Lockable 3.5 mm jack socket
  • Clear and easy focused user interface
  • Long operation time (up to 15 hours)
  • Advanced power management and Li-Ion rechargeables
  • Secure 256 bit AES encryption
  • Remote controllable

Specifications

AF Frequency Response 20 to 20,000 Hz
Dynamic Range > 120 dB (A)
THD (1 kHz) Typ. 0.1 %
Audio Sampling 24 bit/48 kHz
Signal-to-Noise Ratio > 90 dB(A)
Encryption AES 256
RF Frequency Ranges 1,920 to 1,930 MHz
Modulation GFSK with back channel
Transmission Method TDMA, space diversity
Latency 19 ms
Relative Air Humidity Max. 95 %
Temperature Range Operation: 14 °F to 131 °F (-10 °C to 55 °C)
Storage: -4 °F to 158 °F (-20 °C to 70 °C)
RF Output Power Adaptive, up to 250 mW
AF Frequency Response Mic: 50 to 20,000 Hz
Line: 20 to 20,000 Hz
Max. Input Level Mic: 2.2 V RMS
Line: 3.3 V RMS
Line Input Impedance 1 MΩ
Input Sensitivity Automatic sensitivity adjustment
Power Supply Accupack: BA 10 (Li-Ion, 3.7 V)
Batteries: 2 x AA size battery (1.5 V)
Operating Time Accupack: typ. 15 h
Batteries: typ. 10 h
AF Connection Socket 3.5 mm jack socket, lockable
Weight (w/o Accupack) Approx. 0.20 lbs (88 g)

DOCUMENTS

In The Box

  • SL Bodypack DW
  • BA 30 Rechargable Battery
  • Pouch
