Shure 515SBGX Dynamic Cardioid Microphone with Push-To-Talk Switch

Home /
Shure 515SBGX Dynamic Cardioid Paging Microphone with Push-To-Talk Switch (Discontinued)

Description

Details

The Shure 515BGX is a rugged handheld microphone intended for gooseneck or fixed mount with a 5/8"-27 thread. The frequency response is tailored to eliminate low-frequency noise and capture speech with maximum intelligibility. The cardioid polar pattern suppresses feedback and noise from the off-axis sections of the capsule. The 515BGX features a permanently attached with a three-conductor unterminated lead for soldering custom connections. The microphone is a perfect choice for paging and other communication applications.

Features

Features

Frequency response optimized for announcing, narration, and paging applications
Cardioid pickup pattern symmetrical about axis
Neodymium magnet for high signal-to-noise ratio
Shock-mounted cartridge for quiet operation and low stand/handling noise
Tough die-cast locking grille and handle
Built-in push-to-talk

Specification

Frequency Response	80 to 15,000 Hz
Impedance	150 ohms rated (180 ohms actual)
Phasing	Positive pressure on diaphragm produces positive voltage on RED cable relative to BLACK cable lead
Switch	Built-in, leaf-type, non-locking, push-to-talk
Shock Mount	Internal rubber vibration isolator
Cable	Highly durable cable with effective hum shielding, four conductors (two shielded), plastic jacketed
Case	Silver finish die casting with black enamel die-cast grille and stainless steel screen
Furnished Accessories	80A67 Hex Wrench
Net Weight	380 g (13.5 oz)
