| Cartridge Type | Electret Condenser |
|---|---|
| Polar Pattern | Cardioid |
| Frequency Response | 20 to 20,000 Hz |
| Output Impedance | 150 Ω |
| Sensitivity open circuit voltage, @ 1 kHz, typical | –50.5 dBV/Pa (2.5 mV) |
| Maximum SPL 1 kHz at 1% THD | 2500 Ω load: 157.5 dB SPL 1000 Ω load: 153.0 dB SPL |
| Signal-to-Noise Ratio | 63 dB |
| Dynamic Range @ 1 kHz | 2500 Ω load: 126.5 dB 1000 Ω load: 122.0 dB |
| Clipping Level @ 1 kHz, 1% THD | 2500 Ω load: 12.5 dBV 1000 Ω load: 7.5 dBV |
| Self Noise equivalent SPL, A-weighted, typical | 31.0 dB SPL-A |
| Common Mode Rejection 10 to 100,000 kHz | ≥60 dB |
| Polarity | Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 |
| Power Requirements | 11–52 V DC phantom power (IEC-61938), 5.5 mA |
| Dimensions (H x Base x Head of Mic) | 7.18" (182.37 mm) x 0.79" (20.07 mm) x 1.29" (32.77 mm) |
| Weight | 4.6 oz (130 g) |
