Shure KSM8 Dualdyne Vocal Microphone

Name: Shure KSM8 Dualdyne Vocal Microphone
Brand: Shure
SKU: SHURE-KSM8
Price: 439 USD
Availability: InStock

Write a Review

Part #:

KSM8/B

Model #:

KSM8

Current Stock:

MSRP: $549.00

$439.00

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

With two ultra-thin diaphragms and groundbreaking reverse airflow technology, the KSM8 Dualdyne delivers unmatched control of proximity effect, presence peaks, and bleed and requires minimal EQ and processing.

Description

Meticulously crafted for world-class vocal performances and presentations in elite venues, the KSM8 Dualdyne is the revolutionary dynamic microphone that only Shure could make.

Features

Patented cartridge design features two ultra-thin diaphragms (one active and one passive) and a groundbreaking inverted airflow system
Exceptional control of proximity effect greatly increases working distance without on-axis coloration
Neutral mid- and high-frequency reproduction due to controlled proximity effect results in the most natural-sounding dynamic microphone available
Neodymium magnet resides in a micro-injection mold of aerospace SoftMag material, maximizing the magnetic field for the highest output level
Re-imagined Shure Pumping Pneumatic Shock Mount features tuned cavities, specific resistances, and precisely machined components fully integrated into the cartridge’s acoustic properties, delivering exceptional rejection of handling noise without any loss of low-frequency response
Patent-pending Diaphragm Stabilization System technology protects and stabilizes the active diaphragm from unwanted movement from plosives or impact
Dent-resistant, hardened carbon-steel grille design lined with hydrophobic woven fabric provides exceptional water, plosive and wind protection

Specifications

Cartridge Type	Dual-Diaphragm Dynamic (Moving Coil)
Frequency Response	40 to 16,000 Hz
Polar Pattern	Cardioid
Output Impedance	300 ohms
Sensitivityat 1 kHz, Open Circuit Voltage	-51.5 dBV/Pa (2.66 mV)
Polarity	Positive Pressure on Diaphragm Produces Positive Voltage on Pin 2 with Respect to Pin 3
Connector	Three-Pin Professional Audio (XLR), Male
Housing	Die-Cast Aluminum with Paint or Brushed Nickel Finish
Net Weight	0.728 lbs (0.330 kg)
