The Shure SM86 is a unidirectional (cardioid) condenser vocal microphone for professional use in live performance. An extremely rugged microphone, the SM86 with stands the rigors of touring while delivering studio-quality sound.
The tailored frequency response of the SM86 reproduces vocals with clarity. A cardioid pickup pattern isolates the main sound source while minimizing unwanted background noise. The built-in three-point shock mount minimizes handling noise and a two-stage pop filter reduces wind and breath "pop" noise.
| Transducer Type | Condenser (electret bias) |
|---|---|
| Frequency Response | 50 to 18,000 Hz |
| Polar Pattern | Cardioid |
| Output Impedance | 150 Ohms at 1 kHz, Recommended minimum load impedance: 600 Ohms |
| Sensitivity (at 1,000 Hz) | Open Circuit Voltage: -50 dBV/Pa (3.15 mV) |
| Output Clipping Level | 1000 Ohm Load at 1,000 Hz: +3 dBV (1.41 V) |
| Maximum SPL (at 1,000 Hz) | 1000 ohm load (1% THD): 147 dB |
| Self-Noise | 23 dB typical, A-weighted |
| Dynamic Range (1000 ohms) | 124 dB (maximum SPL to A-weighted noise level) |
| Signal-to-Noise Ratio | 71 dB at 94 dB SPL (IEC 651) |
| Power | Phantom Supply Requirement: 11 to 52 Vdc, positive at both pins 2 and 3, Current Drain: 5.2 mA |
| Connector | Three-pin (XLR) professional audio |
| Case | Dark gray enamel-painted steel with matte-finished silver colored steel grille |
| Weight | 0.61 lbs (278 g) |
