Shure MX202WP/C Microflex Overhead Mini Condenser Cardioid Microphone with Plate-Mounted Preamp - White (Discontinued)

Part # MX202WP/C
Model # MX202WP/C

The Shure MX202WP/C overhead microphone delivers clear, accurate audio with interchangeable cartridges and an unobtrusive, bright white design.

Description

Details

Shure MX202 Microflex Overhead Cardioid Microphone

It is hard to believe that such small, unobtrusive microphones can produce such great sound, but it's true. Available in black or white finishes and with inline or plate mount preamps, the Microflex® Overhead condenser microphones capture Shure quality sound in a compact, adjustable package. Each model features a choice of interchangeable cardioid, supercardioid and omnidirectional condenser microphone cartridges attached to a flexible, four inch gooseneck with a 30 foot cable. The preamp options available offer easy installation in ceilings or microphone stands, and when combined with the high sensitivity cartridge's wide frequency response, these microphones provide accurate sound reproduction with a minimum of RF interference or electromagnetic hum.

Features

Features

  • Wide dynamic range and frequency response for accurate sound reproduction across the audio spectrum
  • Interchangeable cartridges that provide an optimal polar pattern choice for each application
  • Balanced, transformerless output for increased immunity to noise over long cable runs
  • White finish that blends unobtrusively with most surroundings
  • White mini-condenser microphone; includes cable and plate-mounted preamplifier
Specification
Frequency Response50 to 17,000 Hz
Output Impedance180 ohms actual (EIA rated at 150 ohms)
Sensitivity (At 1,000 Hz, open circuit voltage)-35.0 dBV/Pa (17.8 mV)
Maximum SPL (1 kHz at 1% THD, 1 k ohm load)124.2 dB
Equivalent Output Noise (A-weighted)28.0 dB SPL
Signal to Noise Ratio (referenced at 94 dB SPL)66.0 dB
Dynamic Range at 1 k ohm load96.2 dB; 100 dB at 0 gain
Common Mode Rejection45.0 dB minimum
Preamplifier Output Clipping Level (1% THD)-6.0 dBV (0.5 V); -12 dBV at 0 gain
Power Requirements11 to 52 Vdc phantom, 2.0 mA
Environmental RequirementsOperating Temperature Range: -18 to 57 degrees C (0 to 135 degrees F) Relative Humidity: 0 to 95%
Weight1 lb (0.45 kg)
