Shure PA821B Antenna Combiner for PSM Wireless Systems
The PA821B active broadband antenna combiner streamlines the simultaneous operation of many PSM systems at a venue. The PA821B combines the RF outputs from up to eight PSM transmitters into one RF output to feed a single transmit antenna. This provides significantly improved reception quality due to reduced intermodulation distortion and dropouts due to multipath interference.
The PA821B is compatible with the wireless personal monitors Shure PSM 300, PSM 900 and PSM 1000.
| Connector Type | BNC (8) |
|---|---|
| Impedance | 50 Ω |
| Operating Temperature Range | -18°C (0°F) to 63°C (145°F) |
| Power Requirements | 100 to 240 V AC, 50-60 Hz |
| Current Drain | 1.59 A (referenced at 100 V AC) (159 VA) |
| Power Consumption | 143 W max. |
| RF Input Configuration | Active |
| RF Frequency Range | 470 - 865 MHz |
| RF Gain | 0 dB (±2 dB) |
| LED Indicator Min. Detection Threshold | 2.5 dBm |
| Expansion Port Configuration | Passive |
| Insertion Loss | < 4 dB |
| Dimensions (H x W x D) | 1.7" (43 mm) x 15.8" (401 mm) x 14.4" (365 mm) |
| Weight | 10.5 lbs (4.8 kg) |
