- Description
Details
Shure SLXD24+/N8C Digital Wireless Handheld System
The SLXD24+/N8C digital wireless handheld system pairs Shure's advanced SLX-D+ digital wireless technology with the powerful Nexadyne 8/C cardioid dynamic microphone to deliver exceptional vocal clarity and consistent RF performance. Designed for live performance, houses of worship, corporate presentations, and installed sound applications, this system provides focused vocal pickup with natural tone and strong off-axis rejection.
Featuring a wide 138 MHz tuning range, the SLX-D+ platform supports up to 11 simultaneous systems in 6 MHz TV bands and up to 14 systems in 8 MHz bands, ensuring flexible frequency coordination across diverse environments. Automatic setup keeps transmitters and receivers linked even in changing RF conditions, while ShowLink Ease technology enables remote frequency changes, RF power adjustments, control locking, and firmware updates directly from the receiver.
For secure and reliable operation, every SLX-D+ system includes AES-256 encryption and Shure's patented Digital Feedback Reducer software to help minimize unwanted feedback. Engineers can monitor and configure systems via Wireless Workbench desktop software or the WWB Mobile app over Wi-Fi or Bluetooth. With up to 8 hours of battery life using AA batteries or the optional SB903 rechargeable battery, the SLXD24+/N8C delivers trusted, professional wireless performance.
- Features
Features
- Nexadyne 8/C cardioid dynamic microphone capsule
- Transparent 24-bit digital audio with >118 dB dynamic range
- 138 MHz wide tuning range for flexible frequency coordination
- Up to 11 systems (6 MHz)/14 systems (8 MHz) simultaneously
- ShowLink Ease remote transmitter control
- AES-256 encrypted wireless transmission
- Embedded Shure Digital Feedback Reducer
- Wireless Workbench and WWB Mobile app compatibility
- Automatic frequency scanning and interference management
- Up to 8 hours battery life (AA or SB903 rechargeable)
- Specification
SLXD4+ Power Requirements 15 VDC @ 360 mA Connector Type BNC Impedance 50Ω Spurious Rejection >75 dB Gain Adjustment Range -18 to +42 dB in 1 dB steps Mic/Line Switch 30 dB pad Network Interface Single Port Ethernet 10/100 Mbps Network Addressing Capability DHCP or Manual IP address Maximum Cable Length 100 m (328 ft) Dimensions (H x W x D) 1.65" (42 mm) x 7.76" (197 mm) x 5.98" (152 mm) Weight 2 lbs (0.91 kg) SLXD2+/N8C Microphone Type Dynamic (Moving Coil) - Nexadyne 8/C Polar Pattern Cardioid Frequency Response 50 Hz - 20 kHz Audio Output Impedance 300Ω Sensitivity -51 dBV/Pa (2.8 mV) @ 1 kHz Digital Audio Format Shure Proprietary 24-bit Digital RF Output Power 1 mW or 10 mW Occupied Bandwidth <200 kHz Battery Type & Life Rechargeable Li-Ion (SB903) or 2x AA (Up to 8 Hours) Construction Rugged Metal Housing Dimensions (Dia x L) 1.46" (37.1 mm) x 6.93" (176 mm) Weight 0.32 lbs (0.15 kg) - Documents
Documents
- In The Box
In The Box
- (1) SLXD4+ Digital Wireless Receiver
- (1) SLXD2+/N8C Handheld Transmitter with Nexadyne 8/C Cardioid Dynamic Microphone
- (1) Microphone Clip
- (2) 1/4 Wave Antennas
- (1) Rackmount Kit
- (2) AA Batteries
- (1) Power Supply
- (1) Carrying Pouch
