The Shure ULXD4 is a half-rack, networkable wireless receiver for use with ULX-D® Digital Wireless Systems.

Description

The Shure ULXD4 is a half-rack, networkable wireless receiver for use with ULX-D® Digital Wireless Systems.

With an expansive set of professional features, including 24-bit / 48 kHz digital audio quality, efficient and intelligent RF performance, and AES 256-bit encryption, ULX Digital offers uncompromising wireless tailored for professional sound reinforcement.

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

Features
  • Predictive switching diversity
  • High Density mode optimizes ULX-D systems to simultaneously operate significantly more channels in applications up to 30 meters
  • Intelligent scanning automatically finds and deploys the cleanest frequencies to transmitters over IR sync
  • Interference detection and alerts provided on both the receiver and Wireless Workbench® 6
  • Front panel gain adjustment buttons provide up to 60 dB additional gain
  • AES 256-bit encryption-enabled for applications where secure transmission is needed
  • Ethernet networking provides streamlined setup across multiple receivers, Wireless Workbench® 6 integration, and AMX/Crestron control
  • Support for frequency coordination with the Axient® Spectrum Manager
  • Rugged metal chassis
  • Intuitive front panel LCD menu and controls with lockout feature
  • Upgraded LCD with adjustable contrast and brightness
  • Audio and RF LED meters with peak indicator
  • Remoteable ½ wave antennas
  • Furnished rack hardware

Specifications
Power Requirements 15 V DC @ 0.6 A, Supplied By External Power Supply (Tip Positive)
Gain Adjustment Range -18 to +42 dB in 1 dB Steps (Plus Mute Setting)
Full Scale Output ¼" (6.35 mm): +12 dBV
XLR: LINE Setting= +18 dBV, MIC Setting= -12 dBV (All Models)
Network Interface Single Port Ethernet 10/100 Mbps
Network Addressing Capability DHCP or Manual IP Address, with or without Gateway
Housing Galvanized Steel
Dimensions H x W x D 1.65" (42 mm) x 6.73" (171 mm) x 7.76" (197 mm)
Weight 2.0 lbs (0.913 kg) Without Antennas
