Shure UR5 Portable Diversity Receiver (Discontinued)

Description

Details

The UR5 is a premium portable wireless receiver component, designed to provide Shure UHF-R®-class technology, performance, and quality for professional broadcast and media production applications. Featuring wide-band frequency tuning, hands-on navigation, rechargeability, and a variety of mounting options, the UR5 is the clear choice for wireless portability.

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

Features

Features

Full bandwidth scan & sync at the touch of a button
2400 selectable frequencies across 60 MHz bandwidth
Audio Reference Companding for crystal-clear audio
Feature-rich, hands-on navigation control
MTx (Multi-transmitter) Mode
Populate multiple transmitters with open frequencies
Headphone monitoring output jack
Mic & Aux-level balanced output
Full range of mounting and power options, including Anton/Bauer plate mounting accessories

Specification

RF Carrier Range	470 – 952 MHz (Varies by Region)
Modulation	FM, ±45 kHz Maximum Deviation
Antenna	Switching Diversity
Dynamic Range	> 100 dBm=, A-Weighted
RF Sensitivity	< -106 dBm for 12dB SINAD, -88 dBm for 30 dB SINAD
Image Rejection	> 100 dB (Typical) (ref. 12dB SINAD)
Spurious Rejection	> 80 dB (Typical) (ref. 12dB SINAD)
Power Requirements	2 AA Alkaline, Shure Lithium-ion Rechargeable Battery, DC Power
Squelch Threshold	30 dB SINAD (±3 dB) Normal Setting
Compatible Channels	Per band: 40 (Band Dependent)
Tuning Bandwidth	60 – 72 MHz (Band Dependent)
Frequency Stability	±2.5 ppm
Pilot Tone	UHF-R Mode: 32 kHz Tone Key Pilot Axient Mode: 28 kHz Tone Key Pilot
Audio Frequency Response	50Hz – 16 kHz
Ultimate Quieting	> 100 dBm=, A-Weighted
Total Harmonic Distortion	< 0.4% THD (Typical) (ref. ±20 kHz Deviation @ 1 kHz)
Signal-To-Noise Ratio	90 dB (Typical) (A-Weighted)
Companding	Patented Shure Audio Reference Companding
Camera Output	Electronically Balanced Configuration: Mono, TA3 Maximum Output Power: Adjustable -35dBV to +10dBV Peak Pin Assignment: Pin 1 = Gnd Pin 2 = Hot Pin 3 = Cold
Headphone Output	Adjustable Range Configuration: Unbalanced Mono (L=R), 1/8 inch Minimum Load Impedance: 9.5 ohms Impedance: 3.5 ohm Maximum output power: 100mW Pin Assignment: Tip = Hot Ring = Hot Sleeve = Gnd
Operating Temperature	T-18°C to +57°C (0°to +135° F)
Battery Life	4 Hours AA Alkaline, 8 Hours Shure Rechargeable Li-ion
Dimensions - (H x W x D)	3.27" (83 mm) x 2.56" (65 mm) x 0.86" (22 mm)
Net Weight	0.200 kg (with AA Batteries)
