The Sony PCM-M10 Portable Linear PCM Recorder is a 96 kHz/24-bit capable recorder with electret condenser stereo microphones, 4 GB of internal flash memory and a microSD/Memory Stick Micro (M2) Slot for expanded memory. Key features of the PCM-M10 recorder include a built-in speaker, cross-memory recording, digital pitch and key control, digital limiter, low-cut filter, track mark functions, a 5-second pre-recording buffer and A-B repeat capability. The recorder includes a USB high-speed port for simple uploading and downloading of native .WAV or .MP3 format recorded files to and from Windows PC or Macintosh computers. The M10 offers durable construction and long battery life using conventional AA alkaline batteries.
| Audio Formats Supported | Record: WAV and MP3; Playback: WAV, MP3, WMA (Non DRM), AAC-LC (Non-DRM) |
|---|---|
| Built-in Mic | Electret condenser microphones. Max input level: 123 dB SPL. Frequency response 20 Hz to 20 kHz |
| Mic Input | Input impedance: 22 k ohm, Rated input level: 2.5 mV; Minimum input level: 0.9 mV |
| Line Input (Analog) | Input impedance: 22k ohms; Minimum input level: 500mV; Rated input level: 2.0V |
| Line Output (Analog) | Line out available from headphone jack (menu selectable) |
| Headphone Output | Stereo Mini Jack; Maximum output: 20 mW + 20 mW; Load impedance: 16 ohms |
| Frequency Response | 20 Hz to 40 kHz (Line in) @ 96KHz |
| Sampling Frequency | 22.05kHz, 44.1kHz, 48kHz and 96kHz |
| Quantization | 16-bit linear, 24-bit linear |
| S/N Ratio | 87dB or greater (1KHz IHF-A) when set to 24-bit |
| Total Harmonic Distortion (Line Input to Line Output) | 0.03% or below (1kHz, 22kHz LPF) |
| Wow and Flutter | Below measurable limit (less than +/-0.001%W.Peak) |
| USB | High-speed USB,mass storage class |
| Power Consumption | 0.27w |
| Power Requirements | Two AA size Alkaline batteries (supplied). Two AA NiMH Rechargable batteries (optional) |
| DC Input Jack | 3V |
| Battery Life | 24 hrs @ 44.1KHz/16-bit or 19 hrs @ 96KHz/24-bit |
| Memory Stick Slot | Accepts Memory Stick Micro (M2) and microSD |
| DC Input Jack | 3V |
| Dimensions (H x W x D) | 4.5" (114.3 mm) x 2.5" (63.5 mm) x 0.875" (22.225 mm) |
| Weight | 0.4125 lbs (6.6 oz) |
