SoundTube CM52-BGM-II
SoundTube CM52-BGM-II 5.25" In-Ceiling Speaker with Seamless Magnetic Grille - White
SoundTube CM52-BGM-II 5.25" In-Ceiling Speaker with Seamless Magnetic Grille - White
SoundTube CM52-BGM-II 5.25" In-Ceiling Speaker with Seamless Magnetic Grille - White
SoundTube CM52-BGM-II 5.25" In-Ceiling Speaker with Seamless Magnetic Grille - White
By SoundTube

SoundTube CM52-BGM-II 5.25" In-Ceiling Speaker with Seamless Magnetic Grille - White

Write a Review
Part #:
CM52-BGM-II-WH
Model #:
CM52-BGM-II
Availability: Limited Stock Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112
Email

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM 1-888-256-4112
Email Contact us by email or
our simple form. SEND EMAIL
The SoundTube CM52-BGM-II features a 5.25" polypropylene woofer with rubber surround and one 0.75" silk dome tweeter. BroadBeam Ring™ technology for mid-range clarity and smooth off-axis performance. Easy-access six-position tap switch for 25 / 70.7 / 100V and transformer bypass settings allows for easy ordering, stocking and installation.

Description

SoundTube CM52-BGM-II-WH 5.25" In-Ceiling Speaker with Seamless Magnetic White Grille

Features one 5.25 inch (134 mm) polypropylene woofer with rubber surround and one 0.75 inch (19 mm) silk dome tweeter. BroadBeam Ring™ technology for mid-range clarity and smooth off axis performance. Easy-access six-position tap switch for 25/70.7/100-volt and transformer bypass settings allows for easy ordering, stocking and installation. Tuned port on baffle for added musicality and bass response down to 65 Hz (-10 dB). Reduced amplification costs and maximum efficiency of 84.5 dB sensitivity, 16 ohm impedance. Incorporates a painted steel grille for lasting durability. Adaptable to material thicknesses ranging from 0.035 in. (0.9 mm) to 1.6 in. (40.6 mm). UL 1480 and 2043 listed.

Included accessories: Color-coded (orange) tile bridge, UL listed conduit clamp, paint shield.

Features
  • One 5.25" (134 mm) polypropylene woofer with rubber surround and one 0.75" (19 mm) silk dome tweeter
  • BroadBeam Ring™ technology for mid-range clarity and smooth off axis performance
  • Easy-access six-position tap switch for 25/70.7/100-volt and transformer bypass settings allows for easy ordering, stocking and installation
  • Tuned port on baffle for added musicality and bass response down to 65 Hz (-10 dB)
  • Reduced amplification costs and maximum efficiency of 84.5 dB sensitivity, 16 ohm impedance
  • Incorporates a painted steel grille for lasting durability
  • Adaptable to material thicknesses ranging from 0.035 in. (0.9 mm) to 1.6 in. (40.6 mm)
  • UL 1480 and 2043 approved
  • Included accessories: Color-coded (orange) tile bridge, UL listed conduit clamp, paint shield

Specifications
Frequency Response (- 3 dB) 67 Hz - 20 kHz
Frequency Response (-10 dB) 56 Hz - 22 kHz
Sensitivity 83.5 dB @ 1W/1M
80.4 dB @ 2.83V/1M
Max. Continuous Power RMS 40W
Max. Program Power 80W
Max SPL dB @ 1 M 100.5 dB
Woofer Driver 5.25" Polypropylene Cone wButyl Rubber Surround
Tweeter Driver 1" Silk Dome w/BroadBeam Ring®
Certifications CE, RoHS, UL1480, UL2043
Included Accessories Conduit Clamp, Cover Plate, Grille, Paint Mask
Optional Accessories White Grille (GRL-CM6/8EZ-II-WH) | Tile Bridge (AC-CMEZ6/8-TB) | Pre-Construction Bracket (AC-CMEZ6/8-PCB) | Junction Box (AC-CM-EZ-JBOX)
Packaging One per box
Backcan Diameter 9.67" (245.6 mm)
Backcan Height 5.75" (146.1 mm)
Visible Diameter 11.75" (298.5 mm)
Visible Height 0.34" (8.6 mm)
Cutout Width/Diameter 10.5" (266.7 mm)
Shipping Weight 9.55 lbs (4.33 kg)
