The SoundTube IPD4-CM62-KIT is a fully integrated in-ceiling audio solution designed for modern networked audio systems. Perfectly compatible with Dante and AES67 protocols, this kit provides scalable, high-quality audio for commercial installations such as offices, retail spaces, and hospitality environments. Its PoE (Power over Ethernet) support ensures easy deployment without the need for separate power cabling.
At the heart of the kit is the IPD4-CM62-BGM-II master speaker. This 6.5" 2-way in-ceiling speaker is IP-addressable and designed to deliver precise, clear sound across a wide listening area. With Dante/AES67 network compatibility, the master unit serves as the control hub for the satellite speakers, ensuring synchronized audio distribution throughout your space.
The kit includes three CM62-BGM-II-WH passive satellite speakers. These high-performance in-ceiling units connect seamlessly to the master speaker, allowing for a flexible and expandable audio setup. The satellite speakers maintain consistent tonal quality and coverage, providing a cohesive sound experience across multiple zones.
Designed with installers in mind, the IPD4-CM62-KIT offers a streamlined setup process and versatile deployment options. Its networked design allows for easy expansion, making it simple to scale your audio system to larger spaces without compromising sound quality. The kit combines convenience, reliability, and professional-grade audio performance, making it an ideal choice for distributed commercial audio systems.
| IPD4-CM62-BGM-II | |
|---|---|
| Speaker Type | 2-way in-ceiling, IP-addressable |
| Woofer | 6.5" low-frequency driver |
| Tweeter | 1" high-frequency driver |
| Network Compatibility | Dante / AES67 |
| Power | PoE (Power over Ethernet) |
| IP Control | Yes, acts as master unit for satellites |
| Frequency Response | 60 Hz - 20 kHz |
| Mounting | In-ceiling, flush mount |
| Visible Dimensions (H x Dia) | 0.34" (8.6 mm) x 11.75" (298.5 mm) |
| Weight | 8 lbs (3.6 kg) |
| CM62-BGM-II-WH | |
| Speaker Type | 2-way in-ceiling passive speaker |
| Woofer | 6.5" low-frequency driver |
| Tweeter | 0.75" high-frequency driver |
| Connectivity | Wired to IPD4-CM62 master |
| Power Handling | Matches master unit output |
| Frequency Response | 70 Hz - 20 kHz |
| Mounting | In-ceiling, flush mount |
| Finish | White (WH), paintable for ceiling integration |
| Visible Dimensions (H x Dia) | 0.34" (8.6 mm) x 11.75" (298.5 mm) |
| Weight | 10.4 lbs (4.72 kg) |
