The compact, 50W, 70V MA501t is now available. Use this versatile little mono amplifier for localized amplification in constant-voltage sound systems. Its small size allows you to mount it on poles, in racks or on a chassis, while its 50W output gives you the power you need for paging and other applications.

Features

Features

Fast, easy Euroblock connections
34 dB gain
25V, 70V and 100V settings
Selectable high-pass filter
Auto-sensing or trigger activation
Measures 1.2" x 3.9" x 8.0"

Specification

Amplifier Power	50W RMS <0.5% THD
Output	25V/70.7V/100V
High Pass Filter – Switchable	120 Hz @ 12 dB/octave
Overall Response	30 Hz – 20 kHz +/- 3 dB @ 1 watt < 0.2% THD
Output Power	50Hz-20 kHz @<1% THD 50W @ 25/70/100V
Power Band Width Response	50Hz - 20 kHz +/- 3 dB
Inputs	RCA Unbalanced/Single Euro Block Balanced
Maximum Input Sensitivity	500 mV for full output
THD+ Noise	<.1% below rated output power
S/N	>84 dB un-weighted
Input Impedance	20K unbalanced, 15K balanced
Protection Features	Amplifier - Overload, Short Circuit, DC and Heat Protection Power Supply - Thermal protection, Over current protection, Short circuit protection
Power Supply	Input: 100-240VAC 50/60 HzOutput: 32 VDC @ 1.6 A
Current consumption 120V	0.6 A/AC
Operating Voltage	100-240 VAC with approved power supply
Regulatory - UL	UL 60065 Listed
Dimensions (H x W x D)	1.25" (32 mm) x 3.9" (100 mm) x 7.9" (200 mm)
Net Weight	1.6 lbs (0.73 kg)
