SoundTube WLL-RX1P-II Tri-Band Uncompressed Wireless Receiver Amp Unit (Limited Stock)

Name: SoundTube WLL-RX1P-II Tri-Band Uncompressed Wireless Receiver Amp Unit (Limited Stock)
Brand: SoundTube
SKU: SOUNDT-WLL-RX1P-II
Price: 470 USD
Availability: InStock

Write a Review

Part #:

WLL-RX1P-II

Model #:

WLL-RX1P-II

Current Stock:

Availability: Discontinued - Limited Stock

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The SoundTube WLL-RX1P-II wireless receiver unit contains a 2-channel 50W/ch Class D amplifier which will power up to two speakers. An additional 5 receivers (for a total of 6) may be ordered to accompany a single transmitter.

Description

SoundTube WLL-RX1P-II Tri-Band Uncompressed Wireless Receiver System

The WLL-RX1P-II wireless receiver unit contains a 2-channel 50W/ch Class D amplifier which will power up to two speakers. An additional 5 receivers (for a total of 6) may be ordered to accompany a single transmitter. Two additional transmitters can be used with separate frequencies with a total of up to 18 receiver units. Each transmitter/receiver contains 3 RF channels to minimize interference from other devices. Each channel contains 3 bands, alternating between them to preemptively counteract interference, keeping the signal clear and latency less than 20ms. Receiver output options include Push-On phoenix connectors or 1/4" connections. The WLL-RX1P also includes stereo line output for connecting auxiliary audio components. A Local Audio source may also be used at the receiver via stereo mini which mutes the wireless signal when connected.

Features

3 RF channels to minimize interference from other devices
Each band contains 3 channels, alternating between them to preemptively counteract interference, keeping the signal clear and latency less than 20 ms
Uncompressed 2-channel audio for maximum fidelity
Multiple receiver/amplifier units may be used with a single transmitter
Up to 6 receivers may be used for each transmitter. For more than 6, use an additional transmitter on another frequency
USB, stereo mini or 1/4" balanced input connections at the transmitter
Push-On or 1/4" connections speaker level outputs at the receiver. Also includes stereo line output for connecting auxiliary audio components, such as ADA (Americans with Disabilities Act) adapters
Local Audio source at the receiver via stereo mini (mutes the wireless signal when connected)
High/Low power selector switch on transmitter limits RF range where needed

Specifications

RF Band	2.4 GHz, 5.2 GHz, 5.8 GHz
Amplifier Output Power	50W/Ch @ 8 Ω, 65W/Ch @ 4 Ω, Bridged Mono 90W @ 4 Ω
Operating Range (Full Power)	210 ft. line of sight
Operating Range (Low Power)	70 ft. line of sight
Audio Frequency Response	20 Hz - 20 kHz
Modulation	Digital
Dynamic Range	90 dB
Antenna Impedance	50 ohm
Power Supply/Requirements	32V, 4.0 A
Housing Material	Powder coated metal
Dimensions (H x W x D)	1.75" (44.45 mm) x 6.18" (156.97 mm) x 6.5" (165.1 mm)
Weight	1.85 lbs (0.84 kg)
