The DSP100-2-CV-D is an affordable, 2 channel, 70V/100V, 1/2 rack amplifier delivering 100W per channel with built in DSP and remote volume control. The DSP100-2-CV-D supports Dante™ audio.

Description

The DSP100-2-CV-D is an affordable amplifier with fully integrated DSP designed to optimize the speakers and overcome the acoustical limitations of a zone. The DSP100-2-CV-D provides 100W from each of the two 70/100V output channels. The robust, full function DSP includes a full cross-point mixer, EQ, filters, limiters, and more. A USB port makes programing simple, fast and repeatable for large installations. The remove volume control operates with a wide range of devices. You won't find a more cost effective way to bring outstanding sound quality to two zones on the market today.

Features

  • Onboard full featured DSP
  • Configurable via USB port
  • Convection cooled, 1/2 rack enclosure
  • 2 balanced + 2 RCA analog line/mic inputs
  • 2 Dante™ input channels
  • Remote Volume Control
  • Made in the USA

Specifications

Output Power 100W x 2 @ 70V / 100V
Frequency Response 65 Hz - 20kHz (70.7/100V)
THD+N
Signal-to-Noise Ratio >100dB
Input Sensitivity 1V (0 dBV)
Input impedance (Balanced/Unbalanced) 20k Ohms/10k Ohms
Amplifier Class D
Remote Volume 0-10V
External Mute Contact-Closure
Input Connectors 3.5mm Euroblock and RCA
Output Connectors 5mm Euroblock
LED Indicators Power, Standby, Signal, and Clip
Controls USB for programming, Level
Optional Network Input Dante® or CobraNet™
Power Supply Input 85-265 VAC 50/60Hz (PFC Universal Input)
Construction Aluminum Chassis
Mounting Rack-Mountable
Cooling Convection–Cooling (No Fans)
Dimensions (height, width, depth) 1.7”H x 8.3” W x 11.25” D
Weight 4.5lbs max
