TeachLogic Forum Classroom System with 4 In-Ceiling Speakers and Microphone (Discontinued)

By TeachLogic

TeachLogic Forum Classroom System with 4 In-Ceiling Speakers and Microphone (Discontinued)

Write a Review

Part #:

IRF-3150/CS-4

Model #:

IRF-3150/CS-4

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The TeachLogic Forum Classroom System is a completely self-contained infrared wireless microphone sound system for portable use or permanent installation.

Description

The TeachLogic Forum Classroom System is a completely self-contained infrared wireless microphone sound system for portable use or permanent installation. The two auxiliary inputs provide multimedia integration with even distribution of sound for all audio in the classroom. It has two separate outputs for assistive listening and recording with active boards.

The SP-628 in-ceiling speaker is a full range compact coaxial ceiling speaker, providing low distortion and a smooth natural frequency response ideal for articulate vocal clarity. The SP-628 has integrated steel backcan along with 24″ tile bridge which allows for quick and easy installation.

The Sapphire is a stylish lightweight classroom microphone. So small, it’s hardly noticeable to wear. It can be worn with a lanyard or clipped directly to your neckline collar. The Sapphire’s vocal clarity is unsurpassed. It boasts high level output, reliable connectivity and exceptional definition. With a built-in breath filter, the Sapphire can also function as a pass-around hand mic.

Features

SP-628 In-Ceiling Speakers:

Air Sealed Metal Back Can for an infinite baffle
6" Cone Driver with a 1" Mylar Dome Tweeter
Frequency Response: 80–15,000 Hz
Power Handling: 30W Continuous
Impedance: 8Ω
Mounting: Three Quick-Mount Clamps
Includes: Galvanized Steel Tile Bridge and 100ft of 18 ga. speaker wire

IMA-320 Forum Amplifier:

Two stereo auxiliary inputs for DVD & Computer/Aux
Additional DVD input gain, adjustable +10 dB boost
Digital Limiting
Front-panel auxiliary input (3.5 mm)
Three-band digital equalizer ± 12dB
Front Panel ALS Output for Assistive Listening system with gain control (3.5 mm)
Front Panel REC output for Lesson Capture with gain control (3.5 mm)
Remote Teacher Priority over line inputs
Power sleep mode to conserve energy
Rack or shelf/wall mounting kits available (optional)
Light Weight Aluminum cover

ICS-55 Ceiling Dome Sensor:

Easily installs on ceiling "T" bar with track bracket
Six large receiving diodes for superior infrared reception
50ft 75 ohm dual-shielded plenum-rated cable

IRT-55 Sapphire Infrared Microphone:

Elegant Design
Only 1.4 oz including battery
Long life “Lithium ion” battery
Rechargeable via micro USB cable (included)
Battery level indicator

Back light under power switch

Momentary mute button, Backlight blinks in mute mode
Push “on/off” power
Channel A or B selectable
Three level mic volume switch (low, medium, high)
Auxiliary input (3.5 mm)
Low profile clip for mounting
Wear with a lanyard or directly to neckline collar with clip

DOCUMENTS

System Includes

(4) SP-628 In-Ceiling Speakers

(4) Steel Tile Bridges
100ft Plenum Rated 18G Speaker Wire

(1) IMA-320 Forum Amplifier
(1) ICS-55 Ceiling Dome Sensor

50ft Plenum Rated Cable

(1) IRT-55 Sapphire Infrared Microphone with Clip

(1) Microphone Lanyard
(1) Rechargeable Lithium-ion Battery
(1) BRC-15 USB Microphone Charger
