TeachLogic Spectrum III Classroom System with 4 In-Ceiling Speakers and Microphone

Home /
TeachLogic Spectrum III Classroom System with 4 In-Ceiling Speakers and Microphone (Discontinued)

Description

Details

TeachLogic Spectrum III Classroom System with 4 In-Ceiling Speakers and Wireless Microphone

The Spectrum III is the optimum sound-field system with 100W of power for large rooms or rooms with high ambient sounds levels. Create a good intelligible learning environment over a large area with up to eight ceiling or wall speakers. The four auxiliary inputs provide multimedia integration with even distribution of sound for all audio in the classroom. RS-232 wall panel control of the line inputs, Fire alarm connection (AC or DC), remote Teacher Security Alert, teacher priority with instant attenuation of the line levels via Sapphire IRT-60 pendant and Digital Feedback Guard (DFG) and switchable computer anti-hum circuit on computer input. The Spectrum III is a four-channel receiver/amplifier with four auxiliary inputs, page pass through, and a 100W amplifier.

The SP-628 in-ceiling speaker is a full range compact coaxial ceiling speaker, providing low distortion and a smooth natural frequency response ideal for articulate vocal clarity. The SP-628 has integrated steel backcan along with 24" tile bridge which allows for quick and easy installation.

The Sapphire is a stylish lightweight classroom microphone. So small, it’s hardly noticeable to wear. It can be worn with a lanyard or clipped directly to your neckline collar. The Sapphire’s vocal clarity is unsurpassed. It boasts high level output, reliable connectivity and exceptional definition. With a built-in breath filter, the Sapphire can also function as a pass-around hand mic.

Features

Features

SP-628 In-Ceiling Speakers:

Air Sealed Metal Back Can for an infinite baffle
6" Cone Driver with a 1" Mylar Dome Tweeter
Frequency Response: 80–15,000 Hz
Power Handling: 30W Continuous
Impedance: 8Ω
Mounting: Three Quick-Mount Clamps
Includes: Galvanized Steel Tile Bridge and 100ft of 18 ga. speaker wire

IMA-820 Spectrum III Amplifier:

Power Amplifiers: 100W total RMS four 25W ea. Digital Hybrid Class D amplifier
Security Alert contact connection
Fire Alarm input AC or DC from 5-24 Volt
Security Alert contact connection
Page Over-ride (muting) with Page Pass-through to classroom speakers input level 100V, 70V, 25V
Four line inputs for DVD, Computer, MP3 & Aux
Auxiliary input (Mic or Line level switch)
Computer Balum anti-hum (On/Off switch)
Front-panel auxiliary input for MP3 (3.5 mm)
DVD input dual RCA on rear panel
Aux and Computer input 3.5 mm on rear panel
Lesson Capture output with level control on rear panel 3.5 mm
ALS output with level control on rear panel 3.5 mm
Five-band equalizer
DFG (Digital Feedback Guard)
Remote Teacher Priority over line inputs
Power up to eight (8) speakers
Power sleep mode to conserve energy
Drop-in charger connection 5volt DC USB
Rack or shelf/wall mounting kits (optional)
