The DA Series multi-channel digital power amplifiers are ideal for multi-zone distributed speaker systems and professional sound applications. Engineered with Class D technology, the new DA Series amplifiers operate at 85 percent efficiency and consume almost one-third less power than conventional analog amplifiers. The compact and lightweight single or dual rack-space design and ultra-low heat dissipation allow designers to rack-mount up to five units without open space between units.
The DA Series is comprised of high and low impedance four-channel models each equipped with an independent power supply for each channel to assure continuous operation and unmatched reliability and performance. Other features include recessed stepped attenuators for precise gain calibration, removable dust filters for easy maintenance, and optional isolation transformer.
| Power Source | 120 V AC, 50/60 Hz |
|---|---|
| Amplification System | Digital class D |
| Power Consumption | 480W (based on UL/CSA standards), 2600W (rated output 8 Ω x 4) |
| Input | 4 circuits, +4 dB (1.23 V, input level control in maximum position) |
| Rated Output (4 channels) | 500W x 4 (9.8 Ω, 70 V line), 550Wx 4 (8 Ω), 100W x 4 (4 Ω) |
| Rated Output (2 channels - BRIDGE) | 1,000W x 2 (19.6 Ω), 1,100W 2 (16 Ω) |
| Rated Output | 8.8 mm (0.35") (M4 screw terminal, distance between barriers) |
| Frequency Response | 20 – 20,000 Hz (–2 dB, +1 dB): HPF OFF50 – 20,000 Hz (–3 dB, +1 dB): HPF ON |
| Total Harmonic Distortion | 0.1% (1 kHz) 0.3% (20 – 20,000 Hz): HPF OFF0.3% (100 – 20,000 Hz): HPF ON |
| Protection Circuit | Protection against excessive current flow due to overload, short circuit, unusual DC voltage output |
| S/N Ratio | 100 dB (A-weighted) |
| Crosstalk | 70 dB (A-weighted) |
| Control Input | Power ON/OFF status channels Photocoupler input drive voltage: 9 V DC (Min) – 14 V (Max), 12 V (Typ) |
| Monitor Output | Withstand voltage: 30 V DC,control current: under 12 mA |
| Connector | RJ45 connector x 2 |
| Connection Cable | Category 5 twisted pair cable for LAN (CAT5-UTP) |
| Maximum Cable Distance | 600 m (656.17 yd) |
| LED Indicator | Power (blue) x 1, Input (green) x 4, Output (yellow) x 4, Peak (red) x 4, Protect (red) x 4 |
| Cooling | Forced air cooling |
| Operating Temperature | –10°C to +40°C (14°F to 104°F) |
| Operating Humidity | Under 90% RH (no condensation) |
| Finish | Panel: Aluminum, black, alumite Case: Plated steel sheet |
| Dimensions (H x W x D) | 3.48" (88.4 mm) x 18.98" (482 mm) x 15.91" (404.2 mm) |
| Weight | 19.4 lbs (8.8 kg) |
