TOA F-05BT 5" 2-Way 120W 70V/100V/8-Ohm Surface Mount Speaker System - Black
Usually arrives in 5-9 business days.
The TOA F-08BT is a premium 8-inch 2-way surface mount speaker system with 180W program power and selectable 70V/100V/8-ohm operation. Its sleek black enclosure delivers powerful, full-range sound with excellent speech intelligibility for commercial indoor audio installations.
The F-08BT is a high-performance 8-inch 2-way surface mount speaker system engineered to provide exceptional audio quality for both background and foreground music, as well as clear public address announcements. Combining a powerful low-frequency driver with a precision high-frequency tweeter, it delivers balanced, full-range sound with enhanced bass response and outstanding vocal clarity, making it ideal for demanding commercial audio applications.
Designed for maximum installation flexibility, the F-08BT supports 70V, 100V, and 8-ohm operation, allowing seamless integration into distributed or low-impedance sound systems. Its modern, low-profile black enclosure blends easily into retail stores, restaurants, hospitality venues, offices, schools, conference rooms, houses of worship, and other commercial environments.
Installation is quick and secure thanks to the included mounting hardware featuring a temporary hanging mechanism that enables single-person installation while simplifying wiring and positioning. The adjustable bracket provides flexible aiming for both wall and ceiling mounting, ensuring optimal sound coverage. Built for reliability and long-term performance, the F-08BT is an excellent choice for professional commercial audio systems requiring powerful output, versatile installation, and premium sound quality.
| Enclosure | Bass-reflex type |
|---|---|
| Rated Input | 60W (100V line, 70V line) |
| Power Handling | Rated noise power: 90W (8Ω) Continuous program: 180W (8Ω) |
| Rated Impedance | 8Ω 100V line: 170Ω (60W), 330Ω (30W), 670Ω (15W), 3.3 kΩ (3W) 70V line: 83Ω (60W), 170Ω (30W), 330Ω (15W), 670Ω (7.5 W), 3.3 kΩ (1.5W) |
| Sensitivity | 91 dB (1W, 1 m) at installation in 1/2 free sound field |
| Frequency Response | 50 Hz - 20 kHz, -10 dB at installation in 1/2 free sound field |
| Crossover Frequency | 3 kHz |
| Directivity Angle | Horizontal: 100°, Vertical: 100° |
| Speaker Component | Low frequency: 20 cm (8") PP cone-type High frequency: 25 mm (1") dome tweeter |
| Input Terminal | Push-in Terminal |
| Installation Environment | Indoor installation |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Finish | Enclosure: HIPS, black (RAL 9011 equivalent), paint Grille: Aluminum, black (RAL 9011 equivalent), paint Speaker bracket: Die-cast aluminum, black (RAL 9011 equivalent), paint Base bracket: Steel plate, t4, black (RAL 9011 equivalent), paint Base bracket cover: HIPS, black (RAL 9011 equivalent) |
| Included Accessories | Speaker bracket x1, Base bracket x1, Base bracket cover x1, Bracket fixing screw set x1 |
| Optional Accessories | Adapter plate: HY-F05B Speaker stand: ST-34B Note: K&M 19780 or K&M 19610 is required |
| Dimensions (H x W x D) | 15.43" (392 mm) x 9.88" (251 mm) x 8.5" (216 mm) |
| Weight | 11.46 lbs (5.2 kg) |
