The F-1000, F-1300 and F-2000 Series speaker systems are designed to provide high quality sound and reliable performance for restaurants, retail and audio/visual applications.
| Enclosure Type | Bass-reflex type |
|---|---|
| Power Handling Capacity | 30 W |
| Rated Impedance | |
| 100 V line | 330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W), 10 kΩ (1 W) |
| 70 V line | 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W) |
| Frequency Response | 80 – 20,000 Hz, –10 dB at installation in a semianechoic field |
| Crossover Frequency | 2 kHz |
| Directivity Angle | Horizontal: 110º, Vertical: 100º |
| Speakers | Woofer: 13 cm (5'') cone-type Tweeter: 25 mm (1'') dome tweeter |
| Input Terminals | Push-in terminals |
| Water Resistance | IPX4 |
| Operating Temperature | –10 ºC to +50 ºC (14ºF to 122ºF) |
| Enclosure | White or Black |
| Mesh Speaker Grill | Surface-treated steel plate, anti-rust paint |
| Speaker Bracket | Aluminum die-cast, White or Black |
| Joint Bracket, Wall Bracket | Stainless steel (SUS 304), t1.5 |
| Dimensions (H x W x D) | 9.84" (250 mm) x " 6.38" (162 mm) x " 6.34" (161 mm) |
| Weight | 3.6 kg (7.94 lbs) (including the supplied brackets) |
