The TOA HS-1500BT is a 15-inch 2-way 300W controlled directivity speaker with selectable 70V and 8-ohm operation. Featuring 90° x 40° coverage, dual input connections, and floor monitor capability, it delivers clear, consistent sound for installed and portable professional audio applications.

Description

TOA HS-1500BT 15-Inch 2-Way Controlled Directivity Speaker

The HS-1500BT is a professional 15-inch 2-way controlled directivity speaker engineered to deliver powerful, intelligible sound for speech and music reinforcement. Its precisely controlled 90° horizontal x 40° vertical coverage pattern helps focus audio where it is needed while minimizing reflections, making it ideal for auditoriums, houses of worship, gymnasiums, conference centers, and other acoustically challenging environments. Finished in black, it blends seamlessly into professional installations.

Designed for maximum installation flexibility, the HS-1500BT supports both 70V distributed audio systems and 8-ohm operation, allowing it to adapt to a wide range of commercial and professional sound applications. Twin input connections with Speakon and screw terminals simplify integration into both permanent and portable systems, while the integrated handle makes transportation and installation easier.

TOA's lightweight coaxial array design reduces size and weight without sacrificing performance. The speaker can also be used as a floor monitor, providing additional versatility for live sound reinforcement and portable AV systems. Combining controlled coverage, installation flexibility, and reliable performance, the HS-1500BT is an excellent solution for demanding commercial audio environments.

Features

  • 15-inch 2-way controlled directivity speaker
  • 300W power handling
  • Selectable 70V and 8-ohm operation
  • Controlled 90° horizontal x 40° vertical sound coverage
  • Excellent speech intelligibility and music reproduction
  • High-efficiency coaxial array design
  • Lightweight enclosure for easier installation and transport
  • Integrated carry handle
  • Twin input connections with Speakon® and screw terminals
  • Suitable for permanent and portable sound systems
  • Can be used as a floor monitor
  • Ideal for commercial sound reinforcement and distributed audio applications

Specifications

Enclosure Sealed type
Rated Input 60W (High Impedance)
Power Handling Continuous pink noise: 100W (Low Impedance)
Continuous program: 300W (Low Impedance)
Rated Impedance
100V line: 170Ω (60W), 330Ω (30W), 670Ω (15W)
70V line: 83Ω (60W), 170Ω (30W), 330Ω (15W), 670Ω (7.5W)
Sensitivity 98 dB (1W, 1 m)
Frequency Response 60 - 20,000 Hz
Crossover Frequency 3 kHz
Directivity Angle Horizontal: 90°, Vertical: 40°
Speaker Component Low frequency: 38 cm (15") cone-type
Input Terminal NEUTRIK NL4MPXX Speakon and M4 screw terminal, distance between barriers: 9 mm (0.35")
Operating Temperature 14°F to 122°F (-10°C to +50°C)
Finish Enclosure: Polypropylene, black
Punched net: Surface-treated steel plate, black
Included Accessories Handle x1, Handle fitting bracket x2, Handle mounting screw x2, Rubber foot x2, Rubber foot mounting screw x2
Optional Accessories HY-1500VB Mounting Bracket (Vertical), HY-1500HB Mounting Bracket (Horizontal), HY-C0801 Ceiling Mount Bracket, HY-W0801 Wall Mount Bracket, ST-33B Speaker Stand
Dimensions (H x W x D) 22.05" (560 mm) x 17.76" (451 mm) x 15.75" (400 mm)
Weight 30.86 lbs (14 kg)
